Item
| Type-A
| Type-B
|
Thickness of strip
| 0.4-0.6mm
| 0.4-0.6mm
|
Strips width
| 54mm
| 65mm
|
Filter Diameter range
| Φ80-400mm
| Φ120-630mm
|
Latin American network expansion width
| 109mm
| 130mm
|
Speed
| 0-6m/min
| 0-6m/min
|
Seams Way
| Inside and outside the flat outer seams
| Inside and outside the flat outer seams
|
Cutting mode
| Pneumatic circular blade cutting track continious non-stop
| Pneumatic circular blade cutting track continious non-stop
|
Total Power
| 4.37 KW
| 4.37 KW
|
Weight
| 1200kg
| 1200kg
|
Dimension
| L1700mm*W1100mm*H1500mm
| L1700mm*W1100mm*H1600mm
|
Seams way
| Pneumatic circular blade cutting track,continuous non-stop
|
Application Material
| Fingerprint resistant sheet, gavanized DX53D+Z board
|
Applicable product
| dust filters, air filters, kinds of interior and exterior mesh filters and supporting mesh etc.
|
