Jal-Kr6-Ov2710 V3.0 2MP Ov2710 Parallele Dvp-Schnittstelle M12 Fester Fokus Kameramodul

Product Description

2MP OV2710 Parallele DVP-Schnittstelle M12 Fester Fokus Kameramodul
Kameramodul Nr. JAL-KR6-OV2710 V3.0

Kameramodul Nr.	JAL-KR6-OV2710 V3.0
Auflösung	2MP
Bildsensor	OV2710
Sensorart	1/2.7"
Pixel Größe	3.0 um x 3.0 um
EFL	3.40 mm
F.NO	2.50
Pixel	1920 x 1080
Betrachtungswinkel	120.0°(DFOV) 85.0°(HFOV) 60.0°(VFOV)
Linsenabmessungen	13.70 x 13.70 x 22.52 mm
Modulgröße	47.85 x 22.00 mm
Modultyp	Fester Fokus
Schnittstelle	DVP-Parallel
Autofokus-VCM-Treiber-IC	Keiner
Linsenmodell	KLT-LENS-MJ7007B
Linsentyp	650 nm IR-Schnitt
Betriebstemperatur	-30°C to +85°C
Gegenstecker	FH12A-24S-0.5SH
