Slant Bed CNC Lathe Machine TCK630GP CNC Turning Lathe

Product Description

Product Description
Detailed Photos
Product Parameters

Performence Features:
The machine is suitable to process all kinds of small and middle-sized shaft and plate work piece,and could also turn
various threads, circle arc, circular arc ,circular cone,inside and outside surfaceof revolved body.
This machine is widely used in sanitary,valve ,electricall appliance,instrument,automobile,motorcycle,bearings and so on.
Higher accuracy Taiwan Linear guideways.
High speed spindle unit.
Higher rigidity cast iron.
Integrated automatic lubrication
45 degree One-piece casting slant bed.
Technical parameter:

Specification	Units	TCK630GP
Max.swing over bed	mm	630
Max.swing over cross slide	mm	300
Max.turning length	mm	1000
Max turning diameter	mm	600
Bed width	mm	466
Bed slant angle	Degree	45°
Spindle nose		A2-8
Spindle motor power	kw	15/18.5
Max.spindle speed	rpm	50-2600
Spindle bore	mm	93
Max diameter through hole	mm	75
Hydraulic 3 jaw chuck	inch	15"
Hydraulic turret		12 stations
Tool shank size	mm	25*25
Boring bar diameter	mm	32
X axis limit Travel	mm	350
Z axis limit Travel	mm	1110
X axis rapid feed	m/min	20
Z axis rapid feed	m/min	20
X axis motor torque	N.m	15
Z axis motor torque	N.m	15
X axis leadscrew		4010-C3
Z axis leadxcrew		4010-C3
X axis linear guideway	mm	45
Z axis linear guideway	mm	45
X/Z axis Positioning accuracy	mm	±0.005
X/Z axis repeatability	mm	±0.003
Tailstock quill diameter	mm	90
Tailstock quill travel	mm	120
Tailstock taper		MT5
Tailstock travel	mm	1280
Machine dimensions	cm	340x220x220
Weight	kg	6000

Standard accessorise:

15" Hollow hydraulic chuck from Taiwan

Hydraulic tail stock

Hydraulic turret 12 stations from Taiwan

Ball leadscrew PMI

Fanuc 0i TF Control system

MPG

Chain type chip conveyor

Cutting Cooling system

Work lamp

Central auto-lubricating system

Tri-color warning lamp

Heat exchanger in cabinet

Full closed guard

Tools and tool box

Levelling bolts and blocks

Optional accessorise:

Power turret BMT or VDI

C axis

Y axis

B axis linear guideway

Tool probe renishaw

Air conditioner in cabinet

Company information
Packaging & Shipping
FAQ

1: What's your main products of your company? A : We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center,
Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on . 2:What kind of controlsdo you use on machines? A :Siemens,GSK ,Fanuc etc. You can choose according to your requirements . 3. What is your trade terms? A : FOB, CFR and CIF all acceptable. 4 : How can I choose the most suitable machines ? A : Please tell me the model or parameter you are interested in, we can provide you with the best price and quality. You can also send us product pictures and we will choose the most suitable machine for you. 5 : Do we receive any updates while machine is in the manufacturing process? A : Of course. The progress of the machine will be updated regularly and sent to you.

---
