FG-1250BIIS Dry Laminating Machine

Product Details

Product Description

Product Description
FG-1250BIIS Dry Laminating Machine Main features Kinds of laminating Dry laminating production technics Suitable material — first substrate BOPP、BOPET、BOPA、laminated film（10-50μm） Suitable material — second substrate CPP、CPE、AL、paper（20-80μm） Application area food packing, commodity packing, others packing Max. working speed Max 250m/min Laminated width 900-1250mm Diameter of the roll Max.φ800mm Structure of the coating unit Two rollers coating structur...
Product Detail
Product TagsFG-1250BIIS Dry Laminating Machine
Main features

Kinds of laminating	Dry laminating production technics
Suitable material — first substrate	BOPP、BOPET、BOPA、laminated film（10-50μm）
Suitable material — second substrate	CPP、CPE、AL、paper（20-80μm）
Application area	food packing, commodity packing, others packing
Max. working speed	Max 250m/min
Laminated width	900-1250mm
Diameter of the roll	Max.φ800mm
Structure of the coating unit	Two rollers coating structure
Coating weight(dry)	Solvent-based: 1.5-4g/㎡Water-based:1 – 3.5 g/㎡
Driven motor power	90.2 kw(not including oven energy source )
Power supply :	380VAC±10%，50±2Hz，three-phase five-wire
Power of the heating supply (oven)	Electric energy supply, steam supply, thermal conductive oil supply
Size( L × W × H)	13500mm×4200mm×3500mm
Weight	28T
Optional function	1. Coating seal spaced blade device 2. Adhesive automatically viscosity control device 3. Sleeve type impressed rubber rollers 4. Fixed point and checking coating control system 5. High-performance energy saving and consumption reducing system 6. Tension control system for dual-film of 2nd unwind device 7. Substrate surface corona device

Production introduction:
★ Summarize and function:
This series of machines is the first one to use the industry computer center control in China. It can accurately control the mulit-motor tension, logic action and coating weight. It already formed three products series including solvent type, solventless type, multi-function type. This series of machines can not only ensure the high quality laminated products but also can furthest reduce the customers’production cost by using the energy-saving, consumption reducing, safety working condition emulational design. The equipment can apply to the multi-layers continuous high speed laminating of the rolled material such as the various bidirectional/ unidirectional stretching plastic film etc.
★ Core competition
①Advanced performance: This series of machines is the 2002 year National Key New Product, National Level Torch Plan Project and Guangdong Province High New Tech Product.. After 15 years of continuous improvement and innovation, we have already formed the full line scientific research & design & precise manufacturing system and full line product specification & grade supply system.
② Stability performance: We have already formed a steady professional team that integrate the scientific research design, product manufacturing and sales service. We coagulate many years’comprehensive resources and win the honor of “Best Product of China ”.
③Technical differences: inner layer laminated substrate is nearly 3-4mm/m; The heat energy consumption of the oven can be reduced 42% – 65 % and the exhaust waste gas of the oven can be reduced 45% – 66%. It is suitable for the laminating technics of water-based adhesive and chemical-based adhesive.
Key components:
★ Final products:
