Vmc Machine High Precision 3-Axis Machining Center Vertical Machine Center Jt-640t CNC Lathe

US$23,000.00-28,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
JT-640T
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
Precision
High Precision
Net Weight
3000kg
Tool Libranes
21 Arm Type Tool Libranes
Standard System
Mitsubishi M80
Transport Package
Seaworthy Packing
Specification
1900*2200*2600mm
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500sets/Year

Product Description



Product Parameters
ITEM UNIT JT-640T
Workbench Workbench size mm 700*700
Worktable load-bearing capacity kg 250
T-slot width (width x spacing x number of slots) mm 14*100*3
Trip X-axis travel mm 600
Y-axis travel mm 400
Z-axis travel mm 350
Distance from spindle end face to workbench mm 170-520
Distance from spindle center to Z-axis rail surface mm 420
Principal axis Speed range rpm 20000
Main spindle power (continuous/30 minute rated) kw 3.7/5.5
Slope of spindle inner hole BT30
Transmission mode
Feed X-axis rapid displacement m/min 48
Y-axis rapid displacement m/min 48
Z-axis rapid displacement m/min 48
Feed rate mm/min 15000
Automatic tool change system Tool magazine capacity set 21
Maximum tool outer diameter (when fully loade mm 65
Expanding the diameter of the hollow blade mm 100
Maximum tool length mm 160
Maximum tool weight kg 2
Tool change time (knife to knife) sec 2
Precision VD13441 (JISB6338) Positioning accuracy mm P0.01(±0.004/300)
Repetitive accuracy mm Ps0.008(±0.003)
Other Electricity dernad Kva 15
Barometric pressure demand (minimum) kg/cm² 5.5
Cuting fluid capacity liter 250
Machine footprint mm(approximately) 1900*2200
Machine height mm(approximately) 2600
Machine weight kg(approximately) 3000
