| Specification | 2U-535: Depth 530*Width 430*Height 88 mm 2U-380AL/2U-3826/2U-3827: Depth 380*Width 430*Height 89 mm |
| Color | Black, Silver |
| Main material | 1.0mm SGCC |
| Motherboard | 2U-535: MAX:CEB(12''*10.5'') 2U-380AL/2U-3826/2U-3827: ATX(12''*9.6'') |
| CD-ROM&HDD | 2U-535: 3.5'' HDD/FDD *7 ; 5.25'' CD-ROM*1 2U-380AL: 3.5'' HDD/FDD *4; 5.25'' CD-ROM*1 2U-3826: 3.5'' HDD/FDD *4 , 5.25" CD-ROM *0 2U-3827: 3.5'' HDD/FDD *4 ; 5.25'' CD-ROM*1 |
| PSU | ATX PSII / 2U Power |
| Panel control | Power Switch x1 ; Reset Switch x1 |
| Panel display LED | Power indicator *1; Hard disk indicator *1 |
| Panel interface | 2U-535: USB2.0 x2 2U-380AL/2U-3826/2U-3827: USB2.0 x1 ; USB3.0 x1(optional) |
| Expansion slot | 2U-535: 7 vertical PCI expansion slots (standard) 2U-380AL/2U-3826/2U-3827: 4 vertical PCI expansion slots |
| Cooling fan | 2U-535: Middle:8025*2 ; back:8025*1 2U-380AL/2U-3826/2U-3827: Front panel 2U-380AL: 8025*2 2U-3826: 8025*3 2U-3827: 8025*2 |
| N.W/G.W | 2U-535: 6kgs/7kgs 2U-380AL: 6kg/7kg 2U-3826: 4.8kg/6kg 2U-3827: 5.1kg/6.3kg |
