Compact Self-Propelled Hydraulic Scissor Lift for Warehouse Operations, Construction and Maintenance

Product Description

Introducing our robust 500kgs 6m Electric Scissor Lift, complete with the prestigious CE Certificate (Model: JCPTZ610HD). Experience unmatched quality and efficiency!
JCPTZ610HD
1. Safe Working Load (S.W.L) of an impressive 500kg, ensuring your operations are worry-free and secure!
2. Reaching up to a remarkable working height of 8 meters, this lift provides the ultimate elevation for all your needs.3. Perfectly designed for accommodating two persons comfortably, enhancing productivity and collaboration. 4. Exceptionally convenient and practical, crafted to simplify your tasks with maximum ease and functionality.5. Enjoy our highly regarded, reliable after-sales service, providing you peace of mind and continuous support.

Machine specifications
SPECIFICATION		JCPTZ610HD	JCPTZ810HD	JCPTZ1010HD
Weight		2150KG	2200KG	2300KG
Overall height		2.19m	2.32m	2.45m
Overall width		1.15m
Overall height		2.48m
Maximum slope		1.5-3°
Gradeability		25%
Maximum Drive Speeds-Stowed		2.5Km/h
Maximum Drive Speeds-Raised		0.8Km/h
Ground clearance		0.1m
Wheelbase		1.9m
front wheels		381*127
Back wheels		381*127
Electrical specifications
SPECIFICATION		JCPTZ610HD	JCPTZ810HD	JCPTZ1010HD
Batteries		4-6V/250Ah
Integrated charger		24V/25A
Drive motors		/
Lifting motor		/
Lifting motor		24VDC/3KW
Platform Data
SPECIFICATION		JCPTZ610HD	JCPTZ810HD	JCPTZ1010HD
S.W.L		500KG	450KG	320KG
S.W.L on extension		112KG
Platform size		2.27*1.12m
Platform extension size		1.2m
Working height		8m	10m	12m
Plaform floor height		6m	8m	10m
Up/Down speed		45/30sec	55/40sec	70/60sec

---
