Automatic Liquid Oil Gel Cream Bottle Filling Machine with Capping Labeling Line

Product Description

Introduction:
Our Cost-effective automatic liquid oil gel cream bottle filling machine with capping labeling line, consisting of bottle turntable, servo piston filling (optional servo pump filling) & servo capping, round labeling and ink jet printing, is suitable for various liquid gel sauce cream bottles jars cans filling capping labeling production, widely used in foodstuff, cosmetics, pharmaceutical, daily chemical, chemical fields auto packaging etc.
Baoneng Machinery professionally customizes the filling line based on specific needs; various bottle feeder, bottle washing machines, bottle filling machines, sealing machines, capping machines, & labeling machines can be equipped for turnkey projects.
Note:
1. Auto linear liquid/paste/powder/granules can/tin filling packaging machine can be customized based on production & space needs.
2. Turnkey project equipment can be available, welcome to contact :)
automatic universal high-speed servo piston liquid cream gel sauce filler with capping labeling line,2000-2500BPH
Main features: This machine adopts servo piston to measure & fill, the sanitary design makes it suitable for filling all kinds of liquids, liquids with certain viscosity, gel, sauce, cream & paste, with wide filling application, easy to operate & maintain. Piston and conveying belt driven by servo motors, with great filling accuracy & easy to dismantle for washing maintenance, very durable and reliable; filling speed & dosage can be directly adjusted on touch screen, with high filling precision & convenient operation. Based on material, the filler hopper can be removed for liquid self-priming, or it can be equipped with liquid level sensors and pump for auto material pumping from user's mixer or tank to our filler hopper, thus making sure continuous cream feeding and stable filling, easy to use. Filling nozzles with anti-drip device, which ensures no phenomena of dripping, and leakage; Filling parts are quick-jointed, easy to dismantle & maintain. With linear and servo design, universal 4-wheel servo capping system and linear round labeller, it's easy and quick to adust meet different bottles production. Adopting servo capping, capping speed and torque can be easily adjusted via touch screen, ensuring good capping quality and fast capping. With PLC program & touch screen man-machine interface system, no bottle no filling, auto counting, one button washing, auto fault alarming, easy to connect filling line, very convenient and easy to operate, with high degree of automation. The machine is mainly made of top-quality SUS304, all material contacting steel parts r SUS304 or SUS316; including the frame; Delicate and durable. Technical parameters: (professional customized for u)

Filling nozzle + capping head	1 nozzle filling + 4-wheel servo capping
Filling way	Servo piston filling (or servo pump filling based on material)
Filling scope	20-200ml/50-500ml/100-1000ml etc (customized)
Capacity	20-40BPM
Filling error	≤ ±0.8%
Air pressure	0.5-0.7MPa
Voltage	220V 50/60Hz 1P
Noise	≤70dB
Machine Power	2.5Kw
labelling	adhesive stickers round labeling (can be surface or sides labeling based on needs)
Dimension	L2000×W850×H1550mm

liquid gel cream sauce filler, automatic universal high-speed servo piston filling machine details fyi
bottle turntable + servo piston filler continous filling without bottle fixing bottle jar turntable + servo filler
servo piston filler + auto pneumatic pump liquid feeding (or pump feeding) servo piston filling + sauce filling nozzle
professionally customizing based on specific materials, bottles, caps, production process, plant layout & capacity etc
quality cost-effective high-speed servo pump liquid/gel/cream filling machine fyi etc
Baoneng Factory ISO cerficate & pump filling capping patented certificates fyi
bottle liquid paste 4-nozzle servo piston filling machine details, easy to adjust for different sizes
Automatic cup pail 6-nozzle servo piston filling machine with auto sealing capping line fyi
Automatic glass bottle sauce paste filling + vacuum capping machine in our factory fyi
Automatic squeeze bottle tomato paste filling machine with servo bottle capping machine line before delivery fyi
glass bottle feeder + UV sterilizer + auto juice sauce filling + vacuum capping machine + labelling in our factory fyi
Automatic bottle liquid/jar paste filling + sealing capping machines before delivery from us fyi
Automatic plastic jar paste filling + sealing capping labeling machines before delivery from us fyi
Packaging before delivery & container loading glimpse in our factory fyi
Meticulous design, Technical Innovation, Rigorous Manufacturing & Attentive servic
auto butter/magarine can feeder + washing + weighing filling + seaming + lid pressing + packaging etc
Quality First, User First, Integrity First is always Baoneng's Business Philosophy
welcome to visit our factroy in Guangzhou, China, contact Tinna for more :)

---
