Full Sexi Video 1080P Full HD LED Screen P4 P5 Indoor Full Color LED Display

Product Description

Product Description (1) Four-level energy-saving technology
Level I dynamic energy saving: when the signal is not displayed, the part of the drive circuit of the constant flow tube chip is turned off;
Level II black screen energy saving: when the display screen is completely black, the static consumption current of the chip drops from 6mA to 0.6mA;
Level III full-screen energy saving: when the low level is maintained for 300ms, the static consumption current of the chip drops from 6mA to 0.5mA;
Level IV shunt power supply step-down energy saving: the current first passes through the lamp bead, and then to the negative electrode of the IC, so that the forward voltage drop becomes smaller, and the conduction internal resistance also becomes smaller.
(2) True color, high-definition visual display
Refresh rate up to 3840Hz, grayscale 16bit, the screen display is realistic and delicate, not harsh, no grainy. Red, green, blue SMD LED beads, good consistency, viewing angle can reach more than 140 °.
(3) Structural optimization and flexible installation
Support floor, hanging, wall mounting and other installation methods. Modular design of module, case and power box, front and rear maintenance, hard connection, structureless installation, saving structural cost.
(4) Drive solutions
With column up and column down fading function, high refresh rate, first row darkening improvement, low gray off-color, pockmark improvement, etc.
(5) Stable and high protection
Outdoor application products, IP66 protection grade, integrated all-aluminum design, corrosion resistance, high melting point, flame retardant and fire resistant, moisture resistant and salt spray resistant, etc., working temperature -40ºC-80ºC, can operate normally in the seaside environment for a long time, with excellent environmental adaptability and outdoor all-weather work.
(6) Stable and reliable performance
Ultra-low temperature rise, low power consumption, low attenuation, plus the aluminum module itself has good thermal conductivity, so that the whole screen has better heat dissipation, no need to install air conditioning, high reliability and long service life.

Product Parameters

Parameter Name	P1.95	P2.604	P2.97	P3.91	P4.81
Pixel structure (SMD)	1415	1415	1415	1921	1921
Pixel pitch (mm)	1.95mm	2.604mm	2.97mm	3.91mm	4.81mm
Module resolution (W×H)	128*128	96*96	84*84	64*64	52*52
Module size (mm)	250*250*18	250*250*18	250*250*18	250*250*18	250*250*18
Module weight (Kg)	1 (die-cast aluminum die set)
Cabinet module composition	2*4/2*3/2*2
Cabinet size (mm)	500*1000*85/500*750*85/500*500*85
Cabinet resolution (W×H)	256*512/256*384/256*256	192*384/192*288/192*192	168*336/168*252/168*168	128*256/128*192/128*128	104*208/104*156/104*104
Cabinet area (m²)	0.5/0.375/0.25
Cabinet weight (Kg)	16/12/8 (die-cast aluminum die set)
Cabinet material	Profile aluminum (box)
Pixel density (dots/m²)	262144	147456	112896	65536	43264
IP rating	IP66
Single-point chromaticity/brightness correction	With
White balance brightness (cd/m²)	4500	4500	4500	4500	4500
Color temperature (K)	6500-9000
Viewing angle (horizontal/vertical)	140°/120°
Contrast Ratio	5000: 1	5000: 1	5000: 1	5000: 1	5000: 1
Maximum power consumption (W/m²)	700	700	700	700	700
Average power consumption (W/m²)	235	235	235	235	235
Maintenance method	Front/Rear Maintenance
Frame rate	50&60Hz
Scanning number (constant current drive)	1/32s	1/24s	1/21s	1/16s	1/13s
Gray scale	65536 levels of gray within any
Refresh frequency (Hz)	3840
Color Processing Bits	16bit
Lifespan(h)	50,000
Operating temperature/humidity range	-10ºC-50ºC/10%RH-98%RH(no condensation)
Storage temperature/humidity range	-20ºC-60ºC/10%RH-98%RH(no condensation)

Product Pictures
Company Profile
FAQ Q: What kind of LED display do you offer?
A: Our products cover LED full color display for indoor and outdoor, rental LED display, LED advertisement display, LED stage display, LED sports display, LED irregular-shape display, customized LED display etc.

Q: How can I get the technical support?
A: We support remote video control at now.
Q: How can you ensure the LED display product quality?
A: Before shippment, all the screens have aging test. And then we also have waterproof test and shake test, ensure products can transportation safety and normal use.

---
