| US$13,900.00-15,600.00 | 1 Piece (MOQ) |
| Machine Specification: | |||||
| - Table size | 1500x 3000mm | ||||
| - Stroke X&Xg Axis | 3100mm | ||||
| Y Axis | 1600mm | ||||
| Z1&Z2 Axis | 200mm | ||||
| - Working height | Max. 200 mm | ||||
| - Rapid speed X&Y Axis | 110 m/min | ||||
| Z Axis | 50 m/min | ||||
| - Spindle type | ATC Air cooling | ||||
| - Spindle speed | 1000 - 24000 RPM | ||||
| - Tool change mode&capacity | Linear Tool Change, 8 tools | ||||
| - Spindle power | 16 HP (9kw) | ||||
| - Vacuum pump power | 7.5HP(5.5kw)-160m3/h | ||||
| -Inverter | Delta 11kw | ||||
| - CNC controller | Syntec / Taiwan LNC | ||||
| - Software for program editor | Type3 | ||||
| Standard Accessories: | |||||
| - Tool holder for router bits | ER-32, HSK-63F | ||||
| - Collet for router bits | ER-32,ψ12~13 mm | ||||
| - vacuum zone | one zone | ||||
| - Dust collecting diameter | φ6" | ||||
| - Packing | Pallet | ||||
