■ On-board 5GHz radio, up to 2475 Mbps physical data rate 8 MB NOR Flash, 256MB NAND Flash
Symbol
| Parameter
|
CPU
| Qualcomm Atheros Quad Core ARM Cortex 64-bit A53 Processor IPQ8072A 2.2GHz CPU
|
CPU Frequency
| Derived from Qualcomm Atheros AP.HK09
|
System Memory
| 1x 512MB, DDR4 2400MHz 16-bit interface
|
Frequency Range
| 2.412~2.472GHz,
5.150~5.825GHz
|
MiniPCIe Slot
| 1x MiniPCIe Slot with PCIe 3.0
|
Modulation Techniques
| OFDMA: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
|
Environmental Temperature
| Operating: -20oC to 70oC,
Storage: -40oC to 90oC
|
Flash
| NOR Flash: 8 MB
NAND Flash: 256MB
|
Wireless
| On-board 4x4 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, max 17dBm per chain
On-board 4x4 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax, max 17dBm per chain
8x U.FL Connectors
|
Reset Buttons
| 1x S/W Reset Button
|
DC Jack Input
| 1x DC Jack Connector: 12V
|
Interface
| 4x 1Gbps Ethernet Port,
2x 2.5Gbps Ethernet Port
2x USB 3.0 Port
1x JTAG 20 Pin Connector
1x Serial Port 4 Pin Connector
|
LED
| 2x RGB LED Indicators
|
Power Consumption
| TBD
|
