| Parameter | Conditions | Min | Type | Max | Units | |
| Freq. Range | Ant - Any Port, Unused Ports -50Ω(1) | 1.1 | 1.7 | GHz | ||
| Gain(2) -Amplified(Norm) -Amplified(Hi Iso) | Ant-Any Port, Unused Ports-50(1) (Gain may be specified by the customer) | 20 | 21 | 24 | dB | |
| 9 | 10 | 11 | ||||
| 0dB | Ant- any Port, ,Unused Ports - 50Ω(1) | -1 | 0 | 1 | dB | |
| Input/output VSWR | All Ports 50Ω(1) | 1.5:1 | 2.0:1 | - | ||
| Noise Figure- Amplified | Ant-Any Port, Unused Ports-50Ω(1) Gain=20dB | 2.0 | dB | |||
| Amp. Balance | ІJ1-J2І,Ant-Any Port, Unused Ports-50Ω(1) | 0.5 | dB | |||
| Phase. Balance | Phase(J1-J2),Ant-Any Port,Unused Port -50Ω(1) | 1.0 | deg | |||
| Delay -Passive -Amplified | Ant-Any Port, Unused Ports-50Ω(1), L1 | 3 | ns | |||
| 5 | ||||||
| Isolation -Amp/Pass(Norm) -Amplified (Hi Iso.) | Adjacent Ports: Ant - 50Ω(1) | 13 | dB | |||
| Alternate Ports: Ant - 50Ω(1) | 21 | |||||
| Adjacent Ports: Ant - 50Ω(1) | 35 | |||||
| Alternate Ports: Ant - 50Ω(1) | 44 | |||||
| DC IN | DC Input on any RF Output | 4 | 12 | VDC | ||
| DC Ripple | 300 Hz to 1MHz | 50 | mV pk-pk | |||
| Device Current | Current Consumption of Active device, excluded Ant. Cur. | 18 | 20 | mA | ||
| Ant/Thru Current(3) | Max source DC current through device | 250 | mA | |||
| Antenna Monitor(4) | Ioc | Range for Open Circuit Threshold | 15 | 75 | mA | |
| Isc | Range for Short Circuit Threshold(5) | 100 | 180 | mA | ||
| Surge Protection | 8/20us | 4 | KA | |||
