Three Axies 250CNC Versatile Machinery for Grinding and Shredding Tasks

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
We are committed to a philosophy of relentless advancement for all our offerings. We reserve the right to modify specifications, mechanics, or designs at any time without prior notice or obligation, ensuring our products remain industry-leading.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., founded in Dongguan City, Guangdong Province, boasts 30 years of expertise in the realm of grinding machine manufacturing, deeply rooted in Taiwan's technological legacy and a wealth of accumulated technical proficiency. In the fast-paced evolution of CNC machine tools, the future is geared towards high-speed precision, composite and intelligent design, open systems, parallel drive capabilities, connectivity, and environmentally conscious solutions. This is the trajectory and future of CNC machine tools. Dongguan Chengyu Machinery Technology Co., Ltd., a dedicated specialist in machine tools and accessories production, upholds a business philosophy of 'technology, innovation, reliability,' coupled with a meticulous quality policy. We are committed to delivering superior products and services, beginning with an in-depth understanding of customers' processes, technologies, and quality requirements. Our design and production technology levels form the backbone of continuous product development, ensuring high automation, precision, and quality. Our fully integrated quality management system, first-class equipment, and exceptional craftsmanship are the cornerstones of our success. In line with market demands, Chengyu Machinery excels in crafting high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We further extend our expertise to the design and integration of industrial robots and automated production lines. Below is a concise overview of our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (Available in servo and hydraulic types) Processing proficiency: Surface grinding and grooving Innovative patented hydraulic control system (hydraulic type) Capabilities: Integrated grinding program for flat surfaces and groove cutting. Versatile feed options: Front, back, left, and right, with memory retention for each grinding program. Automatic shutdown feature activates when grinding wheel experiences overload. II. Available in both servo and hydraulic types Processing versatility: Surface grinding, grooving, and combined scheduling capabilities Innovative patented hydraulic control system (hydraulic type) Features: Comes equipped with a multitude of grinding programs including surface, groove, sole, and side grinding, as well as unequal distance and depth displacement grinding. Advanced grinding wheel dressing: Bottom plane dressing based on set parameters for rough and fine grinding, featuring automatic dressing and compensation within the grinding cycle. Adaptive feed options: Selection of front, back, left, or right, with memory retention for each grinding program. Equidistant and non-equidistant grooving capabilities 3. Four-axis CNC grinding machines available in both horizontal and vertical configurations Processing flexibility: Capable of arbitrary equal division and skipping tooth processing Waist circle configuration: Input based on AB size Triangle fillet configuration: Input requires inscribed circle size B and fillet size R Quadrilateral fillet configuration: Requires entry of side lengths A and B, plus fillet size R Eccentric circle processing: Data input of eccentricity and starting-ending diameters Circle configuration: Input starting and ending diameters for processing Arc: Seamlessly input the desired arc size and specify the rotation angle to achieve precision and accuracy. Step Difference: Effortlessly manage rotation profiles and more to ensure uniformity and consistency in processing tasks. Processing Schedule: Save your processing schedule as a convenient file for effortless retrieval and efficient subsequent operations.

---
