1.Dimension and Weight | L521*W238*H218mm 46KG / 51KG / 56KG / 58KG / 61.5KG | |
2.Functional Parameter | Nominal voltage | 12V |
Nominal capacity (10 hour rate) | 200AH | |
Number of cells | 6 cells | |
3.Rated Capacity at 25℃ (77℉) | 10 hour rate (0.1C, 10.8V) | 200AH |
3 hour rate (0.25C, 10.8V) | 144.7AH | |
1 hour rate (0.55C, 10.5V) | 110.1AH | |
4.Capacity Affected by Temperature (10 hour rate) | 40℃ (104℉) | 103% |
25℃ (77℉) | 100% | |
0℃ (32℉) | 85% | |
-15℃ (5℉) | 65% | |
5.Environment Temperature | Discharge temperature | -20~60℃ |
Charge temperature | 0~50℃ | |
Storage temperature | -20~60℃ | |
6.Inner Resistance & Max. Discharge Current | Fully charged battery at 25℃ (77℉) | 3.5mΩ |
Max. discharge current | 3500A(5s) | |
Short circuit current | 10000A | |
7.Self-discharge at 25℃ (77℉) | Capacity after 3 month storage | 91% |
Capacity after 6 month storage | 82% | |
Capacity after 9 month storage | 73% | |
Capacity after 12 month storage | 64% | |
8.Constant Voltage Charging at 25℃ (77℉) | Cyclic use | 14.4~14.9V |
Maximum charging current | 50A | |
Temperature compensation | -30mV/℃ | |
Float use | 13.6~13.8V | |
Temperature compensation | -20mV/℃ |
