Big Type CNC Vertical Lathe, C5225g*H*2 C5231g*H*20 C5240g*H*20

Product Description

Product description:
Technical parameter :
Technical parameter :

Item	Unit	C5225G*H*20	C5231G*H*20	C5240G*H*20
Max turning diamete	mm	2500	3150	4000
Max workpiece height	mm	1600/2000/2500	2000/2500/3150	2000/2500/3150
Workbench diameter	mm	2250	2830	3150
Max workpiece weight	kg	20000	20000	20000
Max torque of workbench	KN.m	50	50	50
Workbench rpm level		Two stepless speed	Two stepless speed	Two stepless speed
Workbench rpm range	r/min	I gear 0.63*21/II gear 2-63	I gear 0.63*21/II gear 2-63	I gear 0.63*21/II gear 2-63
Tool post rapid feed speed	mm/min	4000	4000	4000
Tool post feed speed range	mm/min	0.5~1000	0.5~1000	0.5~1000
Ram crossface	mm	250*200	250*200	250*200
Main motor power	kw	55	55	55
Machine weight	T	35/38/41	42/45/48	52/55/58

Company information:
FAQ
Q: Are you a trading company or a physical factory?
A: We are a specialized physical factory for more than 10 years. Our machines also gained CE certificate, ISO9001 and EAC certificate.
Q: What's your main products of your company?
A : We specialized in Vertical Machining Center, CNC Lathe, Milling Machines, Lathes, Drilling Machines, Saws, Shapers and so on.

Q: Can you provide customized machine?
A: Yes, we provide customized service for customers to meet different requirements.


Q: Can we visit your factory?
A: Sure, we warmly welcome you to visit our factory at any time. The more you know about us, the more you will trust us! So you can rest assured on our quality machines and our best service.
Q: What's the Payment Terms ?
A : T/T ,30% deposit when order ,70% balance payment before shipment ; Irrevocable LC at sight.
Q: What is your trade terms?
A: FOB, CIF ,DDP and CFR all acceptable.

---
