| Specifications | ZX30 |
| Max. drilling capacity (iron/steel) | Ø31.5/25mm(MT4) |
| Max. mill capacity (face/end) | Ø76/20mm |
| Spindle taper | MT3/R8 |
| Worktable size | 730x210mm |
| Worktable travel (X/Y) | 500/230mm |
| Spindle box swivel degree | 360° |
| Spindle travel | 130mm |
| Spindle nose to worktable | 440mm |
| Spindle speeds | 50HZ:100-2080/60HZ:140-2436rpm |
| Motor | 1.5kw 1450rpm |
| N.W/G.W | 300/350kg |
| Packing size (LxWxH, include foot) | 950x760x1150mm |
| 20' Container | 28sets |
What we can do for you? 1. Experienced staffs answer all your questions in time. 2. Customized design is available, more details to let you know our machines well. 3. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
