| US$45.00-50.00 | 100 Pieces (MOQ) |
| Camera Module No. | KLT-USB1A-AF-IMX335 V2.0 |
| Resolution | 5MP |
| Image Sensor | IMX335 |
| Sensor Type | 1/2.8" |
| Pixel Size | 2.0 um x 2.0 um |
| EFL | 4.15 mm |
| F.NO | 2.00 |
| Pixel | 2592 x 1944 |
| View Angle | 112.0°(DFOV) 92.4°(HFOV) 46.6°(VFOV) |
| Lens Dimensions | 15.00 x 15.00 x 13.42 mm |
| Module Type | Auto Focus |
| Auto Focus VCM Driver IC | Embedded |
| Lens Model | KLT-LENS-PH5005A |
| Interface | USB 3.0 |
| Output Format | MJPG / YUV2 |
| Auto Control | Saturation, Contrast, Acutance White Balance, Exposure |
| Audio | None |
| Input Voltage | DC 5V |
| Working Current | Max 500mA |
| PCB Size | 38mm x 38mm / 32mm x 32mm |
| System Compatibility | Windows XP (SP2, SP3), Vista, 7, 8, 10, 11 Android, Mac OS, Linux or OS with UVC Driver Raspberry Pi by USB Port |
| Software for USB Camera | AMCAP, Webcam Viewer, V4L2 Controls Contacam, VLC Player, MotionEye OS iSpy, ZoneMider, Yawcam |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -30°C to +85°C |
| USB Cable | KLT-Cable-U007 |
