Plastic Extruder Used Continuous Scren Changer

Product Description

Plastic strench film extruder continuous screen changer
Benefits of this extruder polymer continuous screen changer
Increased production
Reduced downtime & scrap
Leak-free operation
Increased filtration area
Reduced inlet pressures
Accurate, repeatable screen changes
Reduced maintenance
Technical data
1)The main body of the screen changer
Raw material: Alloy steel(38CrMoAlA)
Surface treatment: Nitriding treatment
Depth of Nitrated Layer: 0.40-0.70mm
Nitrided hardness: 950-1050Hv
Fragility of nitration: Less than grade 1
Flow channel treatment: Chrome plated
Depth of chromium-plating: 0.05-0.1mm
Hardness of surface after chromium-plating: HV950HV
2)Drive system: Hydraulic unit:
3)Control system
Electrical controlling system: Warnning device, pressure and temperature transducer, are included
Applications
1. Non-woven.
2. Granulation.
3. Pipe.
4. Plate.
5. Sheet.
6. Cast film.
Non-woven fabrics extrusion machine
Plastic granulator
PP/PE/PPR pipe extrusion line
PP/PE plate extruder
Sheet extruder
PET monofilament extrusion machine
PET strap extrusion machine
Quality inspection
We take only first-class steel and check every production procedure to ensure every dimension is produced precisely. A final complete inspection will be executed before delivery. We guarrantee that every set of scren changer from our factory is the best quality.
Packaging
Seaworthy packaging
Commissioning
We provide the operation manual for customers to gudie to install the screen changer, and at the requirement of user, salers should send technician to install and commissioning the die at site of Buyers, expenses of the trip should be borne by Buyers.
After-sales service
12 months with proper operation by user, all the spare parts shall be replaced free of charge under guarantee period, fee for transportation and packing will be borne by users.

Type	Screen D&A		(mm) overall dimension				Heating power (KW))	Output (kg/h)
	(mm)	(CM²)	L	W	H	L1
GM-DP-R-80	Φ60	28x2	180	170	280	700	2.4/3.2	30-180
GM-DP-R-100	Φ80	50x2	220	200	320	810	3.5/4.7	80-280
GM-DP-R-120	Φ100	78x2	250	220	360	970	5.0/7.2	220-480
GM-DP-R-155	Φ130	113x2	320	270	450	1100	8.2/11.1	300-700
GM-DP-R-170	Φ145	165x2	370	310	480	1320	9.4/12.7	400-1100
GM-DP-R-195	Φ165	214x2	400	380	550	1470	10.2/13.8	650-1500
GM-DP-R-220	Φ180	254x2	440	410	590	1620	13/17.5	800-1800
:,. Remark: As the above specification is subject to change without prior notice

---
