Welcome to visit

25L Painting Bucket Plastic Injection Molding Machine Hxm730g with High Performance

US$18,000.00-565,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HXM730G
Type
Plastic Injection Molding Machine
Structure
Horizontal
Plastic Type
PS, ABS, PP, PE, HDPE, PA, EVA
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Energy Saving
Servo Energy Saving
After Sales Service
Engineers Available to Service Machine
Voltage
380V/50Hz, According to Countries
Showroom Locate
Malaysia, Russia, Turkey, Uzbekistan
Condition
New
Injection Weight
2901g PS
Space Between Tie Bar
1000X950 mm
Machine Weight
34 Ton
Transport Package
Standard Package
Specification
10.79x2.45x3.31
Trademark
HIGHSUN
Origin
China
HS Code
8477101090
Production Capacity
7000 Sets / Year

Product Description

1.Picture
MODEL: HXM730-II
TECHNICAL PARAMETER TABLE A B C D
INJECTION UNIT SCREW DIAMETER mm 90 95 100 105
SCREW L/D RATIO L/D 23.2 22 20.9 19.9
INJECTION CAPACITY IN THEORY cm3 2861 3188 3534 3894
INJECTION WEIGHT(PS) g 2603 2901 3216 3543
oz 91.8 102.3 113.4 124.9
INJECTION PRESSURE MPa 195 175 158 143
INJECTION RATE g/s 556 620 687 757
PLASTICIZING CAPACITY g/s 76 85 90 98
SCREW SPEED rpm 110
CLAMPING UNIT CLAMPING FORCE KN 7300
MOVING MOULD-PLATE STROKE mm 950
MAX. MOULD HEIGHT mm 960
MIN. MOULD HEIGHT mm 400
SPACE BETWEEN TIE-BARS (W×H) mm 1000x950
HYDRAULIC EJECTOR FORCE mm 200
HYDRAULIC EJECTOR STROKE KN 280
EJECTOR NUMBER n 17
OTHERS PUMP PRESSURE MPa 16
MOTOR /DRIVING POWER KW 37x2
HEATING CAPACITY KW 48.8
MACHINE DIMENSION (L×W×H) m 10.79x2.45x3.31
MACHINE WEIGHT t 34
OIL TANK CAPACITY L 1315

2.Application
3.Processing,assembling production line
5.Loading containers
6. Customer case
Client in China produce shoe for any famous companies
7.Client in Malaysia
