Woodworking Hard Wood Plywood Veneer CNC Rotary Peeling Clipping Lathe Machine

Product Details

Product Description

Product Description
1. Machine Features
1.Ultra thin rotary cutting, thinnest 0.2mm
2.Use cylinder to hit wood core
3.Alloy lead screw and tin bronze nut
4.Taiwan HIWIN liner Motion Products & Technology
5.Easy knife function, convenient disassembly
6.The surface function is smooth on both sides
7.specialized in cotton wood, pine, birch wood and various hard and miscellaneous tree.
8.Most thick circumflex 4mm
9.Self sheared functiion and whole tail plate
2. Technical Parameters

Length of the peeling wood		970mm-1270mm-1300mm
max log diameter		max500mm min 30mm
roller power	double roller motor	11kw
	single roller motor	5.5kw x 2
	feed motor (servo motor)	11kw
	cutting motor (servo motor)	2.2kw
	rubber roller motor ( a-c motor)	2.2kw
peeling thickness range		0.3mm--4.0mm
peeling output speed		constant speed 60m/min (adjust speed 60m-120m )
reducer modle		R87 helical gear reducer
size of machine		4300mm x 1700mm x1600mm
weight		5500kg
production eficiency (8 Hour)		1.7mm Peeling Veneer 50 m³ 2.2mm Peeling Veneer 60m³ 3.0mm Peeling Veneer 80m³ 3.6 mm Peeling Veneer 90 m³

---
