Ku Band Satellite Dish Flat Antenna 26cm with Sale Price
US$32.00-49.00
10 Pieces
(MOQ)
Basic Info.
Usage
TV
Wave Range
Ku Program
Type
Digital
L.O Frequency
10.75
Input Frequency
11.7-12.75GHz
Output Frequency
950-2050MHz
Gain
60+/-2dB
Keyword
Ku Flat Antenna
Price
Very Reasonable
Certificated
RoHS CE
Transport Package
Standard Carton
Specification
Al
Trademark
BOWEI
Origin
Hefei, Anhui, China
Production Capacity
30000/Month
Product Description
Ku Band Satellite Dish Flat Antenna 26cm with Sale Price Product Description Detail Spec
1.Input frequency :11.70-12.75GHz
2.L.O frequency:10.75GHz
3.L.O stability:10750+/-2MHz(-40°C~+70°C)
4. Output frequency:950~2000MHz
5. Polarization: LinearV/H
6. Polarization switching voltageV:11-14V H:16-20V
7. Gain:60±2 dB
8. Gain :stability+/-2dB(full band)
9. Noise figure:0.6dB
10. Amplitude-frequency:characteristics±2.5dB
11.Phase Noise:75dBc/Hz@10KHz
12. Image Rejection :Ratio45dB
13. operating current:150mA
14. Operating temperature:-40°C~+70°C
15. Relative Humidity:0% to 95%
Company Profile New design universal high quality ku band lnbf with impressive good performance.
High gain and good L.O stability,hot sales in global marketcompany show
