US$3,000.00-8,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Automatic Grade
Semi-Automatic
After-Sales Service Provided
Overseas Service Center Available
Name
Ultrasonic Cleaning Machine
Length of Anilox Roller
100-1800mm
Temperature Control Range
30 C-100 C
Ultrasonic Power Source
20A 220V
Transport Package
Wooden Case
Production Capacity
5000set/Year
Packaging & Delivery
Package Size
1300.00cm * 800.00cm * 600.00cm
Package Gross Weight
300.000kg
Product Description
Product Description
Advantages:
★Economical and practical cleaning equipment with multiple remarkable functions
★Small and exquisite, easy to operate
★Safe and effective cleaning anilox roller
★Suspension type of design, exchangeable and optional between single frequency and double frequency.
Single frequency: 40 KHz, stabilized and reliable, cleaning thoroughly.
Multiple frequencies - after removing stubborn dirt with low frequency, you can clean highly precisely.
★The length of rinsing tank: 1300mm
★The width of rinsing tank: 320mm
★Customized cleansers of different sizes can be available
★Equipped with roller swiveling wheel
★Equipped with heating and constant temperature system
★The waterproof function has been largely improved, which makes the product durable and safe
★Stainless steel shell, making the product more graceful and durable in use
★The cleaning fluid can be made with tap water and a bit of special solvent
★High-power cleaning effect is so significant that can be visible with naked eyes.
Main Technical Variables
The length of anilox roller: 100-1300mm
1.Quantity of vibrators: 39
2. Working frequency of the cleanser: 40 KHz
3. Total power of electric heater: 1.5KW
4.Temperature control range: 30ºC-100ºC
5.Ultrasonic power source: 20A/220V
6. Heating power source of rinsing tank: 220V 20A
It is a modern and advanced cleaning process to clean anilox roller with ultrasonic. The working principle is to make use of transducer to convert ultrasonic frequency electric signals into high-frequency mechanical vibration, which will be transmitted to cleaning fluid. When high-power ultrasonic is transmitted in cleaning fluid, molecules of the cleaning fluid are strongly stirred and vibrated, which leads to the constant generation and cracking of countless steam bubbles. Under the action of ultrasonic, the instant generation and cracking of these bubbles produced powerful impact force, which rapidly removes the printing ink on the surface of anilox roller and in the mesh and realizes the aim of cleaning the anilox roller.
Model | Ultrasonic power (W) | ultrasonic frequency (KHZ) | Heating power (W) | Cleanging width | Number of cleaning | temperature (ºC) |
YB-320 | 960 | 40 | 1000 | 1~320mm | 1~2 | 30~100 |
YB-450 | 1080 | 40 | 1000 | 1~450mm | 1~2 | 30~100 |
YB-650 | 1440 | 40 | 1000 | 1~650mm | 1~2 | 30~100 |
YB-850 | 1620 | 40 | 2000 | 1~850mm | 1~2 | 30~100 |
YB-1000 | 1980 | 40 | 2000 | 1~1050mm | 1~2 | 30~100 |
YB-1200 | 2340 | 40 | 2000 | 1~1280mm | 1~2 | 30~100 |
YB-1300 | 2520 | 40 | 2000 | 1~1360mm | 1~2 | 30~100 |
YB-1500 | 2800 | 40 | 3000 | 1~1560mm | 1~2 | 30~100 |
YB-1800 | 3600 | 40 | 3000 | 1~1860mm | 1~2 | 30~100 |
Detailed Photos
Certifications
Packaging & Shipping
FAQ
Q: Where is your factory located? How can I visit your factory?
A: We are located in wenzhou, you can fly to wenzhou airport. We can pick you up from the airport to your hotel.
Q:How to place my order?
A: Just contact our Trader Manager, E-mail,WhatsApp,Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
Q:Can you offer some video or pictures of the Q packing machine?
A:Yes, of course. Besides, we can help you to have your products packaging if you are available to send us some of your product and then record a video for your reference.
Q:When can I get my machine after I paid?
A:The delivery time is based on the exact machine you confirmed.
Q:Can you design the machine according to our requirements?
A:Yes. We not only can customize the machine according to your technical drawing, but also can make new machine according to your requirements.
>>
