Intelligent and Efficient Guillotine Paper Cutting Machine Paper Cutter Guowei (137S)

Product Description

Intelligent and Efficient Guillotine Paper Cutting Machine | Paper Cutter GUOWEI Computer System Hardware Configuration: It is equipped with a 15.6 - inch full - touch screen manufactured by Taiwan - based FLEXEM. The main board is equipped with an industrial chip imported from the United States. Intelligent Functions: It has the Internet of Things (IoT) functionality, enabling real - time monitoring, collection, and analysis of machine data. It also has a self - diagnostic function for malfunctions, can display the operating mode, and uses a German - designed operating system for convenient operation by users worldwide. Data Processing and Storage: The program storage capacity is 300 program units, and each unit can store 100 cutting - size items. It has the ability to perform four - arithmetic operations and output programs in real - time. Precise Positioning: The backgauge has a position resolution of 0.01mm, with closed - loop control. The positioning error is less than 0.01mm, and the maximum speed can reach 20m/min. The equipment also has a relative positioning function. Convenient Operation: It can quickly locate the cutters, and each air - cushion program can be programmed. The time of automatic cutting signals can be set and canceled. It supports manual and rapid high - low speed switching, automatic paper - pushing, and automatic cutting. Multilingual Support and Safety Assurance: It supports order management in multiple languages such as Chinese and English. The manual and automatic operation modes can be quickly switched. It is equipped with alarm messages, and the main motor will automatically turn off in case of a malfunction. Main Performance Workbench Design: The workbench is chrome - plated and equipped with an air - cushion device, which facilitates the movement of the backgauge and is rust - proof. Transmission System: High - precision ball lead screws and linear guide - rails ensure smooth running of the backgauge, low noise, precise positioning, improve the cutting precision and speed, and extend the service life of the paper cutter. Hydraulic System: It adopts German double - hydraulic technology with adjustable pressure and speed. It is equipped with a second - stage pressure - increasing system and a soft - pressure function, ensuring stable operation within the safe pressure range of 30 - 65000N. Safety Protection: It is equipped with an internal electronic knife locker, as well as safety devices such as a knife - bed safety device, cutting - overload protection device, automatic - return safety device, IR photoelectric protection device, and two - hand - operation - button safety facilities. Component Materials: The large components are made of HT250 cast iron and have undergone natural aging treatment to ensure no deformation during long - term use. Knife - changing and Auxiliary Design: The mechanical knife - replacement assistance device enables quick and safe knife replacement. It is equipped with an illuminated working surface, an optical cutting - line indicator, and a toolbox containing tools, an operation manual, a computer manual, and a spare - parts list. There are 2 standard steel knives as standard equipment. Main Components
Machine Parameter

Model / Specifications	Unit	137
Cutting width	cm	137
	inch	54
Max.cutting height without assistance pressing plate	cm	16.5
	inch	6.5
Max.cutting depth	cm	145
	inch	57
Min cutting depth without assistance pressing plate	cm	3
	inch	1.2
Extended length of working table	cm	74
	inch	29.1
Height of working table	cm	89-92
	inch	35-36.2
Machine width including side working table	cm	287
	inch	113
Total length of working table	cm	259
	inch	102
Cutting speed	r/min	47
Max. Paper pressure	n	45000
Power of main motor	kw	4
Motor for paper feeding	kw	1
Air pump	kw	0.75
Machine weight	kg	4000

Configuration Listing

No.	Name	Brand,Specification & model	Origin of Brand
1	Background LCD	15.6"Color touch interface FLEXEM	Taiwan Joint venture
2	Internet of Things(IoT)	real-time monitoring, data collection and analysis of machine
3	Programmable Logic Controller(PLC)	Panasonic	Japan
4	Back gauge position motor	NIDEC Servo motor	Japan
5	Pick-up/sensor	Omron	Japan
6	Limit switch	PANASONIC	Japan
7	Guarding motor	Schneider	France
8	Air Switch	LS	Korea
9	AC Contactor	Schneider	France
10	Miniature Relay	IDEC	Japan
11	Switching power supply	MW	Taiwan
12	Power switch	Shuangke	Taiwan
13	Press-button	BOCHENG	China
14	Ball screw	High accurate	Taiwan
15	Linear guider	High accurate double linear guides	Taiwan
16	Hydraulic system	Combination valve	Germany
17	Oil Pump	Marzocchi	Italy
18	Bearing	NSK	Japan
19	Working table	Slotless and plated chromium work table	China

Installation Size

Model	Unit	A	F	H	G	B	J	I	M
137	Cm	287	259	173	89-92	230	74	59	76
	Inch	113	102	68	35-36.2	91	29.1	23.2	30

.
CREATE VALUE FOR CUSTOMER IS OUR TARGET! CONTACT US NOW!

---
