Automatic 30L Container Single or Double Station Blowing Molding Machine

US$50,000.00-150,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
GM-30L
Raw Material
PE
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
After-sales Service
Online/Engineer
Plastic Material
PE ,PP , Ab,ABS
Transport Package
Film
Specification
30L
Trademark
GM
Origin
China
HS Code
8477301000
Production Capacity
20sets/Year

Product Description


automatic 30L container single or double station blowing molding machine
Suitable for PE, PP, PVC, PETG, PS, EVA, ABS, TPU, etc all kinds of plastic hollow level;Can produce 5 ml to 5000 l plastic buckets, bottle, pot of hollow plastic containers and tools such as bags, counterweight plate, traffic facilities, medical apparatus and instruments, automobile tail, duct, desktop, plastic tray, airline seats and other kinds of hollow plastic products
Main parameters
Specification Unit
Raw material PE.PP.ABS......
Max size L 30
capacity Pc/hr 50
Dimension M 4.3×2.4×2.9
Weight ton 8.2
Clamping unit
Clamping force KN 150
Template spacing mm 410-820
Template size mm 550×600
Max molds size(W*H) mm 550×580
Thickness of molds mm 560
Drive
screw fan power KW 0.18×3
air pressure Mpa 0.8
Air consumption m³/min 0.8
Cooling water pressure Mpa 0.3
Avg consumption power KW 35
oil pump power KW 15
Extrusion system
Screw diameter mm 75
screw rate of L/D L/D 25
Plastic capacity Kg/hr 90
screw heating zone zone 4
screw heating power KW 14.5
extrusion motor power KW 30
Die head
die head heating zone Zone 4
die head heating power KW 9.5
max extrusion mouth diameter mm 215
