Aioties New Half Cell Dual Glass Solar Module 680W 685W 690W 695W 700W Bifacial Monocrystalline Solar Panel for Home Power System

Product Description

Model Type	MY-M12TB/132-680	MY-M12TB/132-685	MY-M12TB/132-690	MY-M12TB/132-695	MY-M12TB/132-700
Rated Maximum Power at STC	680W	685W	690W	695W	700W
Maximum Power Voltage (Vmp)	42.08V	42.32V	42.55V	42.77V	43V
Maximum Power Current (Imp)	16.16A	16.19A	16.22A	16.25A	16.28A
Open Circuit Voltage (Voc)	49.51V	49.71V	49.91V	50.11V	50.31V
Short Circuit Current (Isc)	17.13A	17.15A	17.17A	17.19A	17.21A
Module Efficiency	21.89%	22.06%	22.22%	22.37%	22.54%
Working Conditions&Working Conditions
Operating Temperature		-40°c~+85°c
Maximum System Voltage		1500VDC(IEC)
Maximum Series Fuse		35A
Power Tolerance		0~+3%
Temperature Coefficient of Pmax		-0.24%/°c
Temperature Coefficient of Voc		-0.22%/°c
Temperature Coefficient of Isc		+0.047%/°c
Refer.Bifacial Factor:			90±5%
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2, Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S;45±2ºC

MY SOLAR TECHNOLOGY CO., LTD.established in December 2010, is a member of MY Solar group, which is specializing in the desian, manufacture and sales of PV modules and correlative products.Our management team is experienced and professional. Our core products - PV modules, are rational designed, excellent in workmanship, and have a stable performance, power range covers 3Wp-400Wp, are widely used in photovoltaic power stations, BIPV & BAPV, satellite communications, geological monitoring andforest fire prevention, etc. Our products are exported to Europe, America, Asia- Pacific and Africa.MY Solar is a core supplier of many key large projects in China, and is also a supplier of photovoitaic modules and correlative products which is selected, trusted and recommended by many professional designing institutes.
Q:What's your payment terms?
A:T/T,L/C,Paypal,Western Union etc.
Q:What are the advantages of your company?
A:We are a factory, and we also cooperate with other brands,such as Longi,JA solar,Jinko,Trina,Canadian Solar,GCL,SUNTECH,Yingli etc., to provide customers with better prices and more choices.
Q:May I have a piece of sample to check the quality?
A:Welcome to place the testing order to check the quality or for testing.
Q:How about the delivery time?
A:15-20 days after receiving your payment.
The specific delivery time depends on the items and the order quantity.
Q:Where is the port of loading?
A:Shanghai,Ningbo.
Q:Can you do OEM?
A:Yes.

---
