Homogeneous Multi-Stage Emulsifying Mixing Shearing Pump with 30KW Motor
| Product Name: | Multi-Stage Homogeneous Emulsifying Pump |
| Material: | Stainless steel 316L/1.4404 |
| Seal Material: | FPM(Viton) |
| Max. Flow: | 50 m3/H |
| Max. Power: | 90KW |
| Temperature: | -20~140 degree centigrade |
| Media refinement: | ≤ 100 GRIT (≈200 μm) |
| Mechanical seal: | SIC/C/FKM(Standard), optional: SIC/SIC/FKM, SIC/C/FFKM, SIC/SIC/FFKM |
| Surface treatment: | RA≤0.8μm, optianl: 0.6μm/0.4μm |
| Mechanical seal: | Double mechanical seal |
| Motor: | ABB/domestic |
| Motor Frequency: | 50HZ, 60HZ |
| Available connection: | Tri-Clamped, Threaded, Flanged connection |
| Available standard: | DIN, SMS, 3A, RJT, ISO, IDF |
| Operated: | By electric motor |
| Low discharge : | With bottom drain valve, sampling valve |
| Trolley: | Optional |
| Control box: | Optional |
| Motor cover: | Optional |
| Certification: | 3-A-02-11(N.O.1579); MD/06/42-EC(N.O.70521616101-00); FDA 177.2600;
USP CLASS-II; EG/VO1935/2004; |
| Application scope: | Dairy, food, beverage, pharmacy, cosmetics etc |
| Packaging Details: | By plywood case |
1. Maintenance, disassembly and installation can be completed without need of professionals and special tools.
2. When in installation and debugging, the motor won't be damaged even if with a short reverse rotation.
3. Impeller and shaft are connected by key groove.
