Customized FOTON brand 4*2 RHD diesel engine mini 10,000 day old chick transported van truck for sale
Customized FOTON brand 4*2 RHD diesel engine mini day old chick transported van truck for sale, adopts FOTON 4*2 TM RHD(right hand drive) single row driver cab, 2400mm wheelbase, QC480Q 40hp diesel engine, 5 speed manual gearbox, 2tons rear axle, 175R14 tires, etc.
The cold van body dimension of FOTON mini diesel engine day old chicks transported carrier is 2600*1600*1600 (mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation
Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective. The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation
Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective.
more information,please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
More pictures of FOTON mini diesel engine day old chick transported truck is as below.
main technical parameters of FOTON Brand 4*2 RHD mini day old chicks transported truck for sale,
Overview
|
Product name
| FOTON brand 4*2 RHD diesel day old chick truck
|
Dimension(L*W*H)(mm)
| 4745*1707*2445
|
Total mass(kgs)
| 3045
|
Rated payload(kgs)
| 1350
|
Kerb weight(kgs)
| 1565
|
Driver cab seats
| 2(driver included)
|
Approach/departure angle(°)
| 24/28
|
The parameters of chassis
|
Truck chassis manufacturer
| FOTON
|
Driving type
| 4*2 RHD(Left hand drive)
|
Wheelbase(mm)
| 2400
|
Gearbox
| MG70 5 speed manual gearbox
|
Front/rear track(mm)
| 1320/1410
|
Tyre specification
| 175R14
|
Front/rear suspension(mm)
| 895/1075
|
Leaf Spring number
| -/5
|
The parameters of engine
|
Engine manufactuer/model
| QUANCHAI
|
Engine rated power(hp)
| 40hp
|
Fuel type
| Diesel/oil
|
Displacement/capacity(ml)
| 1809
|
Emission standard
| Euro Ⅰ
|
Max .torque
| 104N.m
|
The parameters of van body
|
Van box body dimension(L*W*H)(mm)
| 2600*1600*1600
|
Material
| 2.2mm external fiberglass, internal 2mm stainless steel, sandwish 80mm XPS
|
Rubber sealing
| Equipped
|
Van body skeleton rim
| Aluminum
|
Doorframe and locks
| Stainless steel material
|
Lighting
| LED lights
|
Cooking and heating
| CARRIER refrigerated unit cooling and water heating
|
Ventilations
| Both van body sides total with 6 windows(3*2), , ceiling sky-windows 2 pcs; ceiling ventilations fans 4 pcs(2*2), rear door ventilations 2pcs, upper sides ventilation vent, floor ventilation vent
|
Shelves
| Two sides and tiltable
|
Batteries
| 2 sets of batteries instead of generator unit
|
Day old chicks transported vehicle is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
Baby chicks van truck is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.
The poultry transported truck is mounted on the truck chassis, choosing high quality, high strength FRP materials with high-tech Sandwich crafts working.
The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
>>
