Zhj-100-G Paper Edge Board Machine

Product Description

Product Description Edge board machine is used to make the L shape /U shape and flatboard edge protector in high speed. This machines consists of paper reel stands (13 layers, 1 layer face paper, 12 layers of core paper), gluing unit, Edge wrapping unit, Pressing unit, Cutting unit and output conveyor.
2. Technical datas::

Dimensions for L shape	25 X 25mm up to 100 X 100mm
Dimensions for U shape	Inner width 20-70 , two sides height: 20-60 2-6
Dimension for flatboard	width: 40-150mm
Wall thickness	L : 2-8mm	U shape: 2-6mm		Flatboard: 2-7mm
Cutting length	50mm up to maximum as required
cutting precision(tolerance)	+ - 0.5mm
Production rate	L : 0-40m/min	U: 0-30m/min	Flatboard: 0-35m/min
Main power	14kw , 380V/50Hz
Weight	4.5 tons
Layout space	32000*800*1600mm

2. Features:
2.1 To make paper edge protectors, paper angle board, paper corner pieces
2.2 Manufactured in steel frame, national standard angle bar ,10mm thickness steel sheet, guaranteeing rigidity and stability
2.3 Speed control: through frequency inverter
Packaging & Shipping

Packaging Details: Packed in the wooden box or as requested
Shipping Details: We can accept different shipping methods in different situation, such as, the whole machine line should be shipped by sea, small spare parts can be delivered by express or by air.
Delivery Detail: 60days after we get the down payment
Company Information Wuxi shenxi Honeycomb Machinery Factory, started in honeycomb machinery engineering since year of 2000. During the past 14 years, shenxi honeycomb has developped from octoganal honeycomb core machine, cascading type honeycomb machine, to full- automatic honeycomb core and paperboard prodution line and high speed edge board line. Until now, shenxi has exported to USA, UK, Italy, Turkey, Spain, Lithuania, India, Malaysia , South Africa etc. over 30 countries. Make the honeycomb and edge board machine working more automatic and more simple is our developping mission.

Our Services Shenxi Honeycomb Has exported to over 22 countries, we will dispatch three engineers for installation of each project. Regarding to after sales service, we will support customer through email, video meeting and extra spare parts. Besides, we can dispatch engineers for after sales if necessary.

---
