HAS VIDEO Square bottom gift paper bag making machine price

Product Details

Product Description

Product Description
Square bottom gift paper bag making machine price
Machine working video: http://youtu.be/RLuGjGLn0dc (please copy)
All paper bag making machine working video:
/playlist?list=PLnDMbEqgt27xor_FtBV1TrKtM_gbygOTT
(please copy)
Product Description
1. Features:
Paper Bag Making machine can produce the square bottom paper bag in conjunction with overseas
advanced technology. The machine has many advantages such as high speed,high productive efficiency
and wide-rang adjustment.
It is an ideal machine for producing Square Bottom Shopping bags to pack gifts, cosmetic, etc.
2. Advantages:
1)Suited for 60-180gsm roll sheet paper.
2)Controls bag length through the human-machine interface.
3)PLC system for calculating parameters.
4)Equipped with an accurate photocell system.
5) Color mark error automatic alarming and stopping system
6)Automatic oil lubrication system and Automatic counting system
3.Technical Parameters:

MODEL	CY-290	CY-460
Width of Paper roll	320-930 mm	600-1300 mm
Length of Bag	155-505 mm	155-505 mm
Width of Bag	80-290 mm	220-460 mm
Width of Bag Bottom	60-160 mm	60-180 mm
Paper weight	60-180 g/m2	60-180 g/m2
Max. Diameter of Paper Roll	1500 mm	1500 mm
Internal Diameter of Roll Core	76 mm	76 mm
Max.Speed	200 pcs/min	200 pcs/min
Total Power	15Kw	15Kw
Weight of Machine	Approx 9000 kg	Approx 10000 kg
Overall Dimension(L*W*H)	8600 mm × 2500 mm × 1800 mm	8600 mm × 3000 mm × 1800 mm

4.Machine Pictures:
5. Sample Pictures:
Packaging & Shipping
Our Services
Our engineer can be available to service machinery overseas.
1)We have several senior engineers service in many countries, all the year round with our after-sales office in multiple countries.
2)Machines with good quality in one year, life-long maintenance.
3)We have many machines can be monitored via the Internet, solve customer requirements in
a timely manner.
4)We have several senior,continuous innovation and reform, in order to ensure the quality of
mechanical stability.
5)Undertake various non-standard machinery, solve the customers' requirements.
Company Information
PAPER BAG MAKING MACHINE
We are specializing in making paper bag making production line, including paper bag making machine, flexo printing machine, rope making machine and handling making machine etc.
We have both paper bag making machine with roll feeder and sheet feeder.
1.Company Show
2. Certificates
4. Contact Information:
Contact Person: Tracy Wu SKYPE:XIAOHAIMACHINE
Mobile:+86-137777712080 Tel:+86-577-256933332
Add:Shangwang Industrial, Ruian city, Zhejiang province, China
Web:www.xiaohai-machin
Business Name Card of QR code:
FAQ


Company Profile
Wenzhou Xiaohai Import And Export Co., Ltd
We are a Big Group specializing in making all kinds of printing and plastic machines, such as plastic bag whole line machines (film blowing machines, flexo and gravure printing machines, lamination machines, all kinds of bag making machines), disposable glove making machines, plastic cup and paper cup making whole line machines, drink straw making whole line machines, label whole line making machines, and paper cutting whole line machines.
