Competitivefood Jam Homogenizer and Disperser China Manufacturer

Product Description

Product Description
ZX2000 is a high-performance online colloid mill that can perform wet grinding and coarse and fine grinding of hard and granular raw materials. It is especially suitable for producing colloidal solutions or extremely fine emulsions and suspensions. Excellent dispersion properties allow this machine to be used in continuous processes, providing a narrow distribution range of ground particles in a single pass. For difficult grinding tasks, the colloid mill can be installed via a pipe connection into a recirculation circuit with a working vessel.
If you want to best adapt the machine to process requirements, you can equip it with different grinding heads. Helical gear tools and transverse gear tools are available.
The tapered geometry of the grinding head allows axial rotation of the stator, allowing infinite adjustment of the grinding gap. This allows the dispersion effect to be adjusted, especially for many different raw materials.
Since the rotor and stator do not have continuous chutes, the probability of particles passing through the generator without being processed is extremely small. These common characteristics allow the colloid mill to reduce the particle size to the smallest size, thereby obtaining similar
dispersion effects at a higher flow rate, which can compete with high-pressure homogenizers. Detailed Photos
Our Advantages
• High throughput combined with excellent grinding results
• Customize different grinding heads to achieve various grinding shear rates
• Infinitely adjustable stator/rotor gap setting for reduced particle size control
• Suitable for materials in various viscosity ranges up to 50,000 mPas
• Able to operate at pressures up to 16 bar
• Easily scale up production from laboratory machine development to mass production machines
• All wetted parts are 316L or 316Ti stainless steel
• High-performance mechanical seal with wear-resistant material
• High quality surface treatment for easy cleaning
• Other materials and finishes available on request
• The machine can auTomatically drain water and has CIP and SIP functions
• Low noise

Product Parameters
applications industry
Packaging & Shipping

---
