| US$4,500.00-6,500.00 | 1 Piece (MOQ) |
| The trolley-type design makes work more convenient Storage & Convenience: The trolley is designed with extra storage space for tools and other items. Equipped with ergonomic handles and high quality wheels that allow for easy steering and direction changes, it is easy to manoeuvre in confined areas. Reduced labour intensity: Through the use of leverage and wheels, the trolley can be easily handled, reducing labour intensity. | |
| Double Red Light independent development high speed Galvo Strategic cooperation with ZBTK, adopting self-developed double red light design for higher stability. Easy to find the focal point, so that the cleaning efficiency is more efficient. | |
| JPT laser source The Geput CL series is a high power fiber laser using a direct electrically modulated semiconductor laser as a seed source (MOPA) solution, with perfect laser characteristics and good pulse shape control ability, using a lightweight laser output head, while maintaining the excellent performance of laser anti-high reaction, which has outstanding advantages in laser cleaning. | |
| Powerful software,support 25 language switching With 25 languages and user-defined process parameters, users canquickly select welding parameters according to different materials andthicknesses.The operation is simple and faster, saving novice trainingand production costs. | |
| Better cleaning effect 8 cleaning modes optional Supports 8 cleaning modes, which can be applied to many kinscomplex cleaning scenarios. Support slow rise and slow drop of laserpower real time control, better cleaning effect, no damage to the sub.strate. | |
| Cleaning head can be held or wheel propelled Adopts self-developed holder, the product structure design is morereasonable and the stability is higher, better improve cleaning efficiency. Wheel propelled device, fixed focal length and clean more evenly.It can maintain the ideal focal length without adjustment high cleaning finish. All directional protection and protection of the lens, can be moresafe and stable in the working environment of, betterimprove cleaning efficiency. | |
| 2 years warranty The machine come with 2 years warranty, stable and high cost-effective. Amachines use famous brand parts, with strict quality inspection. LME lasermachine. customer's best choice. welcome the masses of customer to trust to purchase. |
| No. | Parameter Name | Description |
| 1 | Product Name | Pulse fiber laser cleaning machine |
| 2 | Laser power | 100W / 200W /300w |
| 3 | Wavelength type | Pulse |
| 4 | Power stability | better than 5% |
| 5 | Power adjustment range(%) | 10-100 (gradient adjustable) |
| 6 | Repetition frequency(KHz) | 20-200 (gradient adjustable) |
| 7 | Fiber length | 5m |
| 8 | Cooling method | Air-cooling |
| 9 | Scanning range | 5mm ~ 120mm , Continuously adjustable |
| 10 | Focal length of field lens ( mm ) | 160mm (Optional 160mm-500mm ) |
| 11 | Depth of focus | max 10mm |
| 12 | cleaning head weight | about 1kg |
| 13 | voltage | 110V/ 220V |
| 14 | working temperature | 5ºC~ 40ºC |
