Product Details
Product Description
Product Description
The baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc. More information, please feel free to contact with Ms. Anita.
Truck for transported day old chick is a kind of special insulation van truck for transporting day old chickens and eggs, etc. It is suitable for large chick farms, etc.
High-Tech Day Old Chicken Truck transporting
1)Day old chicken truck adopt with whole skeleton of the “sandwich” plate bonding process,
2)Inner and outer plate use glass fiber reinforced plastic (GFRP) and steel; so have thermal insulation ;
3)Intermediate insulation materials used 7cm thick imported polyurethane;
4)Surroundings use aluminum edge;
5)Bottom plate use steel and wood to fix the body, good insulation and nice overall intensity. so the frame have firm and better load bearing.
6) The bottom plate use optional ventilation slots to facilitate air-conditioned flow of the entire cargo, and maintain the balance of the temperature.
SINO TRUK HOWO 4*2 LHD day old chick truck, adopts high quality SINO TRUK HOWO 1880mm single row driver cab, 3360mm wheelbase, CY4102BZLQ 120hp Euro 3 diesel engine, 6 speed manual gearbox, 2.4tons front axle/4.2tons rear axle, 7.00R16 rail tires, etc.
HOWO light duty chick baby transported truck is with the overall dimension (L*W*H): 5995×2220×3100 (mm), chick van body dimension (L*W*H): 4100×2040×1800 (mm).
The baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc.
If you're interested in our day old chick transported truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
main techical parameters of SINO TRUK HOWO 4*2 20,000 day old chick transported truck is as below.
Product name
| SINO TRUK HOWO 4*2 LHD day old chick transported truck
|
Overall dimension(L*W*H)(mm)
| 5995×2220×3100
| Chick van box dimension(L*W*H)mm
| 4100×2040×1800(mm).
|
Drive type
| 4*2 LHD
| Total mass
| 4495
|
Gearbox
| 6 speed transmission, manual
| Tyre specification
| 7.00R16 rail tyres *6+1
|
Power steering
| Yes
| Exhaust braking
| Yes
|
Air-cut braking
| Yes
| Driver cab
| SINO TRUK HOWO 1880mm single row driver cab without air conditioner
|
Engine
| CY4102BZLQ
| Emission standard
| Euro 3
|
Rater power
| 88KW/120hp
| Displacement (ml)
| 3856
|
Main technical parameters of day old chick van body
Performance and consumption
|
Heating system
| Watering system
| Without, client choose to install
|
Cooling system
| One refrigerated reefer
| China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab)
|
Ventilation system
| Air duct installed on the floor for air flow
| Two line as the pictures show
|
Cold air duct installed on the double sides of the van body
| Two lines as the pictures show
|
Blind windows
| 3 sets of blind windows with smaller doors for the left and right van sides (as the pictures show), 2 sets of blind windows for the front plate.
Blind Windows: 3*2+2=8
|
electronic ventilator fans
| 1, 2 sets of electronic ventilator fans with sliding doors for the rear plate door; 3 sets of electronic ventilator fans for the van top
Electronic fans: 2+3*2=8
|
| Sky-window
| Top mounted sky windows*2 Sky-windows: 2*1=2
|
Dimension
|
Chick van box body
| Length
| 4100mm
|
Width
| 2040mm
|
Height
| 1800m
|
Refrigerated van box
| Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices;
Aluminum-patterned baseplate;
|
More pictures of SINO TRUK HOWO 4*2 20,00 day old chicks transported van vehicle is as below.
Day old chicks transported vehicle is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.
There are ventilation and heating system inside the farm poultry transported truck. There are several electronic ventilator fans (according to the length of the insulation van) on the top for ventilating, assuring offering enough oxygen for the baby young chicks/ducks/ gooses in the van. There are several windows (according to the length of the chick box body) for ventilating, heating, oxygen-offering.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita. The hot sale line is 0086 13329899995.
>>
