CO2 Carbonation Machine for Soft Drink

Product Description

CO2 Carbonation Machine for Soft Drink
1 Capacity 1000-10000L/H
2 Quick Steady Accurate
3 PLC Controllled
4 CE/ISO
(1) QHS series mixing machine/beverage machine (drink mixer) is designed and made for improving the proportion of water, syrup and carbon dioxide.
(2) This beverage mixing machine adopts foreign advanced technology-static mixer to lighten water layer and increases the carbonized time and assure mixing result.
(3) This mixing machine adopts high-quality water pump and seimens electrical equipment and other parts to form complete automatic control system.
(4) It is suitable for mixing all kinds of drink. Such as soda water, fruit juice. Cola and other soft and hard drink.
Main Technical Specifications of the mixing machine/beveage machine

Model	1500	3000		4000			6000
Water-sugar mixing proportion	3:1-10:1
CO2/H2O	>2.6
Intel temperature of the chilled water(0C)	3-5
Working pressure of precarbonation vessel and syrup vessel	0.05-0.08Mpa
Working pressure of storage vessel	0.2-0.5Mpa
Production capacity (kg/h)	1500		2500		4000	6000
Power(kw)	1.5		2.42		3.5	5.1
Overall dimensions (mm)	1200×1000×1800		1500×1000×2000		1650×1300×2000	1900×1300×2250
Weight (kg)	600		800		1300	2500

---
