Precise Flow Control Excavator with Improved Operating Space

Product Description

Precise Flow Control Excavator with Improved Operating Space Product Description
Technical Strength
Flexible operation
It is more flexible in narrow space operation thanks to the zero-tail swing that does not exceed the track.
Comfortable and humanized
With the comprehensively upgraded ROPS cab, the operating space is improved by 15%. The driving comfort is also better thanks to an air conditioner(warm&cool) and internal and external air circulation systems.
Excellent performance
Customized load sensing hydraulic system realizes precise flow control. The micro-action controllability is improved by 20% and simultaneous action coordination is improved by 5%.
Easy maintenance
The rear and right hood can be fully opened at a large angle, with the centralized layout of frequently-used maintenance parts, making daily maintenance time-saving and labor-saving.
Product Parameters

ITEM	UNIT	VALUE
Operating Weight	kg	3790
Bucket Capacity	m³	0.1
Rated Power	kW/rpm	18.2/2200
Max. Drawbar Pull	kN	31.6
Bucket Digging Force	kN	31.5
Arm Digging Force	kN	19.5
Max. digging height	mm	4860
Max. digging depth	mm	3005
Max. digging radius	mm	5525

Detailed Photos
