16000lbs Large Capacity Winch with ISO

Product Description

Features:
1. High efficiency and energy saving motor.
2. New heavy-duty sealed contact with silver-alloy contact pads, being long life and high quality
3. Patent brake being more reliability and safety
4. O-ring sealed, protecting motor from water and dust
5. Aircraft grade wire rope, or synthetic rope is optional
6. Remote switch & wireless remote control being alternative
7. Using ENGO iron supports becoming stronger
Specification:

Rated line pull:	16000Lbs (7258kgs) single line
Motor:	Series wound 6.8hp /5.0kw,12V DC
Gear Train:	3 stage planetary
Gear ratio:	345: 1
Clutch:	Sliding Ring gear
Braking action:	Automatic in the drum
Fairlead:	Roller fairlead for wire rope
Wire rope:	11.5mmX26m
Drum size:	3.5"×8.8"(88mm×224mm)
Dimensions:	23.9"×8.5"×9.4"( 608mm×216mm×239mm)
Mounting bolt pattern:	10"×4.5"(254mm×114.3mm)
Battery:	Recommended 650 CCA minimum for winching 25 square mm,72"(1.83m)
N.W:	132lbs (60kgs)
Packing:	700mmx300mmx400mm (300pcs per 20' container)
Line speed and motor current (first layer)
Line pull	Lbs	0	2000	6000	12000	16000
	Kgs	0	907	2722	5443	7258
Line speed	FPM	19.7	12.5	8.2	6.2	4.3
	MPM	6	3.8	2.5	1.9	1.3
Motor current	Amps	70	120	200	290	420
Line pull and cable capacity
Layer of cable		1	2	3	4
Rated line pull per layer	Lbs	16000	14720	12580	9960
	Kgs	7258	6677	5706	4518
Cable capacity per layer	Ft.	17.6	37	63	85
	M	5.4	11.4	19.4	26

Shipping Service
We can arrange you transportation, we have our own shipping and express company, or we can use your forwarder.

How to choose a ZHME Winch for your vehicle
Can't decide which winch is right for you? The best way to choose is to calculate the line pull needed for the application. To do this multiply your vehicle's Gross Vehicle Weight (GVW) by 1.5 - this will give an approximation for how big your winch should be. Typically, the first layer of rope around the drum is the max load the winch is capable of. Each additional layer deducts about 10% off the rated line pull. So for a winch rated 9,500lbs, the second layer will pull 8,550lbs, the third 7,700lbs, etc. A loss of pulling power can also be experienced when the rope isn't spooled evenly on the drum. So re-spool your winch before you go out!

---
