Three Axies 250CNC Versatile Grinding Machine for Industrial Use and More

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
Cheng Yu Machinery Technology Co., Ltd. proudly upholds a relentless commitment to the continuous enhancement of our entire product line. We reserve the privilege to evolve our designs, specifications, and mechanics without prior notice, showcasing our dedication to innovation and exceptional service.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., established in the dynamic city of Dongguan, Guangdong Province, stands as a beacon of precision engineering, backed by 30 years of unparalleled Taiwanese experience in grinding machine manufacturing. Our team is composed of highly skilled technicians dedicated to pushing the boundaries of technology. As we witness the swift evolution of CNC machine tools, the industry is heading towards high-speed, high-precision solutions that are composite, intelligent, and open. Our focus aligns with the trends of parallel drive, networking, and eco-friendly practices, guiding the future of CNC advancements. Dongguan Chengyu Machinery Technology Co., Ltd. excels in producing and processing top-tier machine tools and accessories. Driven by our core values of 'technology, innovation, and reliability,' we adhere to a meticulous quality policy to deliver superior products and unforgettable customer service. From conceptualizing customer needs to realizing high-automation solutions, our scientific quality management, advanced equipment, and exceptional craftsmanship elevate us in the CNC industry landscape. Meeting the market's growing demands, Chengyu Machinery offers a diverse array of high-precision CNC solutions, including surface grinders, forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. Our prowess extends to designing industrial robots and automated production lines, with cutting-edge integrated applications. Explore our CNC grinding machine series for a glimpse into our innovation: I. HS Series - Models 618 / 250 / 3060 / 4080 / 40100 (Available in both servo and hydraulic types) Processing Capabilities: Delivering exceptional surface grinding and precise grooving functionality. Revolutionary patented hydraulic control system (for hydraulic models) ensures optimal performance. Functions: Comes equipped with versatile grinding programs, including flat surface and groove cutting. Flexible Feed Modes: Customize your feed options (front, back, left, right) and rely on memory for each grinding program. Safety Feature: Grinding wheel overload protection with automatic shutdown for enhanced safety. II. Comprehensive Models (servo and hydraulic types available) Processing Capabilities: Mastering surface grinding, grooving, and complex scheduling with ease. Distinct patented hydraulic control system (hydraulic models) for superior control. Advanced Functions: Ready with a variety of grinding programs for surface, groove, sole, side, and uneven depth displacement grinding. Automated Wheel Dressing: Experience precise bottom plane dressing with set rough/fine grinding, complete with automatic dressing and compensation within grinding cycles. Versatile Feed Modes: Selectable feed options (front, back, left, right) with memory retention for grinding programs. Innovative Grooving: Equidistant and non-equidistant groove capabilities for tailored results. 3. Versatile Four-axis CNC Grinding Machines available in both horizontal and vertical configurations. Processing Types: Capable of arbitrary equal division and advanced skipping tooth processing. Precision Waist Circle: Input AB size for precise engineering. Flawless Triangle Fillet: Enter inscribed circle size B and fillet size R for exacting details. Perfect Quadrilateral Fillet: Input side lengths A and B with fillet size R for immaculate results. Eccentric Circle Mastery: Input eccentricity and diameters for starting and ending points. Circular Excellence: Input starting and ending diameters for impeccable circular formations. Arc: Simply enter the desired arc size along with the precise rotation angle to achieve flawless results. Step difference, rotation profile, and more: Easily manage and control your machining parameters. Processing schedule: Effortlessly save and retrieve your processing file for convenient future access and seamless operations.

---
