Caustic Chemical Storage Transportation Equipment Al2543 LPG Loading Arm

Product Description

The structure for AL2543 land loading arm:
The general introduction for land loading arm:
Our land loading arm is especially designed for transporting fluid between piping system and tanker, which shall be designed for different tanker, liquids and site conditions.
Equipped with loading platform, folding stairs and safety cage to make the land loading arm into a complete loading system.
By level location or quantitative monitoring, while fluid level exceed the present value, provide the sound and visual alarm or the remote signal.
According to the products, models and requirements of customers, the operating modes could be manual, pneumatic or hydraulic etc.

The basic technical data for AL2543 land loading arm:

AL2543 is a typical of bottom loading arms, mainly for the products such as LPG, liquid ammonia, liquid chlorine, etc. This type of loading arm usually connects to tanker by flanges or quick coupling. It has good sealing performance.
Places Applied	Bottom closed loading or unloading
Applications	Products which are easy to gasify at normal temperature and pressure.
Nominal Diameter	DN50~DN80 (liquid), DN25~DN50 (vapour)
Working Temperature	-196~250ºC
Working Pressure	PN1.0~PN4.0
Material of pipeline	Carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc.

Our loading arm in the workshop or on site:
Overseas project cases:

---
