| Input Voltage | 9-36V DC |
| Wattage | 100W |
| Raw Lumens | 9500lm |
| Beam pattern | Driving beam / Spot beam |
| Intensity | 1 lux @442m/577m |
| Reference No. | 45 |
| Available size | 14inch / 20inch |
| Dimension | 20inch (516*58*81mm) |
| IP Rating | Comply with IP68, IP69K |
| Optic system | Side Reflector |
| LED | 10pcs*10W LEDs |
| Connector | DT4 |
| Life Span | 50,000+ hours |
| Other Spec. | Integrated ETM Technology to extends life span |
| Certification | ECE R112, R7, R10 / CE / RoHS |
