| TABLE | Worktable size | mm | 1000*500 |
| T-Slot (Quantity*Width*Distance) | mm | 5*18*100 | |
| Max load of worktable | kg | 500 | |
| TRAVEL | X/Y/Z axis travel | mm | 860/510/560 |
| X/Y/Z axis guideway type | mm | Linear guideway | |
| Distance from spindle center to column | mm | 607 | |
| Distance from spindle nose to table | mm | 145~705 | |
| FEED RATE | Rapid traverse of X/Y/Z axis | m/min | 36/36/30 |
| Cutting feed rate | mm/min | 0~10000 | |
| SPINDLE | Max spindle speed | r/min | 12000 |
| Spindle taper | No.40 (7:24) | ||
| ATC system | Tool magazine capacity | 24T/Arm | |
| Tool shank type | BT40 | ||
| Max tool weight | kg | 8 | |
| Max tool diameter (w/o adjacent tools) | mm | 24T: φ78/155 | |
| Max tool length | mm | 300 | |
| Time of tool change (T-T) | s | 24T: 2.5 | |
| ACCURACY | X/Y/Z axis positioning accuracy | mm | 0.008/0.008/0.008 |
| X/Y/Z axis repeatability accuracy | mm | 0.005/0.005/0.005 | |
| CONTROL SYSTEM | Controller | GSK/SIEMENS/FANUC |
