11 Conductors Irrigation Cable for Center Pivot Irrigation System Span

Product Description

The irrigation cable is designed to operate electric motor driving pivot system, Irrigation cable is rated 75ºC and permitted for 600V application
Conductors: Soft annealed stranded copper, bare or coated
Size: 18AWG-4/0AWG
Insulation: PE. Thickness: per UL 1263
Number of conductors: 4, 10, 11
Inner jacket: Flame-retardant PVC, Minimum average wall thickness 0.76mm
Shield: Corrugated aluminum specially coated and applied in order to bond to the outer jacket with a total minimum thickness of 0.2mm
Outer jacket: Sunlight resistant PE. Minimum average wall thickness 1.27mm
Information on the jacket: AWG or kcmil size, conductor type letters, rated voltage, the name of the manufacturer, UL file number.
Size AWG: 14/4, 12/4+16/7, 12/4+14/7, 10/4+14/7, 14/4+18/6, 12/4+14/6, 10/4+14/6.

---
