Plastic Single Screw Extruder Double Three Triple a+Ba Layer PPR PE HDPE LLDPE Irrigation Water Supply Energy Gas Plumb Hose Pipe Tube Extrusion Production Line

Product Description

Plastic Single Screw Extruder Double Three Triple A+B+A Layer PPR PE HDPE LLDPE Irrigation Water Supply Energy Gas plumb Hose Pipe Tube Extrusion Production Line
Product Description
PE pipe production line is primarily used in the manufacturing of PE pipes with diameters ranging from 16mm to 1200mm. The various thickness of the pipes produced can make them suitable for applications range from urban water supply to gas transportation. This line also excels in the production of anti-flammable and anti-static electricity pipes using a two- or three-layer spiral mold for use in mining industries. Pipes produced feature even wall-thickness and perfect roundness. Through switching or adding certain part of machine unit, this line can also be customized to extrude pipes of various other kinds.
Features
The optimum spiral structure-feeding throat highly improves the output of extruder;
Accurate temperature control system ensures materials melting performance;
Unique screw design achieves better plasticizing and high-quality products;
Precisely designed gearbox with a high torsion guarantees stable running;
"H" shape frame to decrease vibrating of extruder;
Advanced PLC operation system realizes synchronization and automation;
Adopt automatic water temperature & level control and special independent filters on both vacuum and cooling tanks;
Offer stable haul-off unit with 2-12 caterpillars;
Provide saw & chip-free cutting options;
Low energy consumption, excellent performance, and easy maintenance.
Product Parameters

Item/Model	GF63	GF110	GF160	GF250	GF315	GF630	GF800
Diameter range/mm	16-63	16-110	50-160	50-250	110-315	315-630	400-800
Claw number of haul off/pcs	2	2	2	3	4	6	8
Pulling force/KN	6	8	11	20	30	40	50
Pulling speed/meter/minute	15	12	8	9	4	2	2

Remarks: all information above is only for refererence; please gather the exact data by contacting us.
Detailed Photos
Machining Equipment
Electric Components
Business Cooperation
