RAM Milling Machine CNC Machine Is Optional

Product Description

Big accuracy milling machine with big ram travel ISO40
Product Parameters

Items	XQ6432	XQ6432A	XQ6432B	XQ6432C
Working area
Worktable size (L×W)	1270x320mm	1370x320mm	1270x320mm	1370x320mm
T slot (Width x No. x pitch)	14x3x80mm
Max. load of table	300kg
Table rotation	optional: ±45˚
Distance from horizontal spindle axis to table surface	65-465mm
Distance from vertical spindle nose to table surface	250-650mm
Travels
Worktable longitudinal travel (X)	720mm	820mm	900mm	1000mm
Worktable cross travel (Y)	300mm (If with DRO:280mm)		380mm (If with DRO:360mm)
Worktable vertical travel (Z)	400mm
Ram travel	460mm
Spindle
Horizontal spindle speed	12 steps; 35-1500rpm
Spindle taper(Horizontal)	7:24, ISO40
Motor power(Horizontal)	3kW
Universal milling head spindle speed	11 steps; 45-1660rpm
Spindle taper(Universal milling head)	7:24, ISO40
Universal milling head swivel angel	±360°
Motor power (Universal milling head)	3kW
Feed
Rapid feed (X/Y/Z)	1335/1335/1000mm/min
Feed range (X/Y)	30-830mm/min
Feed range (Z)	23-625mm/min
Others
Machine size (L×W×H)	1720x1680x1860mm	1820x1680x1860mm	1720x1680x1860mm	1820x1680x1860mm
Net weight	1850kg	1900kg	1900kg	1950kg

other models

Items	XL6436	XL6436C	XL6436CL
Working area
Worktable size (L×W)	1325x360mm	1325x360mm	1600x360mm
T slot (Width x No. x pitch)	18x3x80mm
Max. load of table	350kg
±45°table rotation	optional
Distance from horizontal spindle center to worktable surface	0-450mm
Distance from spindle nose to table surface	175-625mm
Travels
Worktable longitudinal travel (X)	750mm	1100mm	1300mm
Worktable cross travel (Y)	320mm
Worktable vertical travel (Z)	450mm
Ram travel	550mm
Spindle
Horizontal spindle speed	12 steps; 60-1800rpm
Spindle taper(Horizontal)	7:24, ISO50
Motor power(Horizontal)	5.5kW
Universal milling head spindle speed	12 steps; 60-1750rpm
Spindle taper(Universal milling head)	7:24, ISO50
Universal milling head swivel angel	±360°
Motor power (Universal milling head)	4kW
Feed
Rapid feed (X/Y/Z)	1200/800/600mm/min
Feed range (X)	30-750mm/min
Feed range (Y)	20-500mm/min
Feed range (Z)	15-375mm/min
Servo motor torque	15Nm
Others
Machine size (L×W×H)	1800x2100x2000mm	2245x2100x2000mm		2520x2100x2000mm
Net weight	2685kg	2750kg		2800kg

Detailed Photos
√ universal 360° swivel head can process any angle surface √ 27 speeds spindle, gearbox driven directly, wide speed range for powerful milling √ power driven sliding ram, very long travel in Y-axis
√ 500x2000 mm large work-table, long travel
√ double-supporting-column design, 1800kg heavy load capacity

√ table feeding is driven by 3 independent servo motors, high accuracy, low noise, can achieve 3-axis synchronous feeding
√ 3-axis ball screws for good precise
√ 3-axis E-handwheels on control panel, manual feeding is easy and precise √ scientific circult design for easy maintenance
Configuration
optional configuration
Certifications

Packaging & Shipping
Delivery time: generally 3 months production time after confirmation of order
Packing type: machine need to be dismantled to load into container, covered with damp-proof plastic film, then packed in thickened water-proof cover on steel pallet
Company Hot Products Link

Company Profile
Tengzhou Xili Machine Tool Co., Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. Our company is located in the scenic hometown of Mozi who is the famous thinker in ancient China.It covers an area of about 20000 square meters. Our fixed assets are 20 million RMB. There are 430 workers, including 132 technicians. We are equipped with 18 sets of precision processing machines and 260 sets of testers. Our company is a high tech enterprise for strong technical strength. With business management standardization and perfect sales and after-sales service, we have established the best brand of "YOU RONG XI LI"Our main products include vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, RAM type milling machines and vertical drilling machines with all 30 categories.In 2003, we attained ISO9001 quality guarantee system certification. With more than 10 years′ history of milling machine production, we have advanced technology and rich managing experience. Our milling machine was ranked the first place in China. We are capable of designing and manufacturing special machine tools which sell well all over country and are exported to the USA, Germany, Britain, Southeast Asia, the Middle East and Africa.Our company insists on "professional services and creating value for customers". We provide high quality products, reasonable prices, satisfactory service and timely delivery. President Li Jian and all staff welcome all customers from at home and abroad to visit our factory.
FAQ

1. What is the MOQ ?Minimum order quantity is 1 set.2. What is the payment term ?Usually we prefer T/T. 30% deposit, 70% balance payment against machine ready to delivery photos and videos.Other payment terms are also acceptable after discussion.3. What is the trade terms ?Usually is FOB.Others like CIF, CFR, EXW...... are also acceptable.4. How long is the guarantee ?12 month after machine's delivery from factory.Within warranty, we guarantee spare parts free of charge and online supports for installation, operation, maintance and trouble shooting etc.5. What kinds of machines do you supply?Company specialized in producing CNC & manual milling machines. Include:CNC gantry machining centerVertical machining centerSimple NC milling machineConventional manual milling machines (Vertical, Horizontal, Universal, Turret mill, Swivel head mill, Power sliding ram type, Bed type, Tool milling machine, Gantry type etc.)5. How can I believe your company ?XILI Machine Tool has more than 20 years milling machine production history, covers an area of about 50000 square meters, with 20 million CNY fixed assets and more than 200 employees.Xili Machine Co., Ltd. is a ISO9001 company, all products are with CE certificate.Welcome your inquiry and visiting.

---
