| Out Shell | Shell Material | 6063-T5 Aluminum Alloy | |
| Thickness | 1.0mm | ||
| Technology | Plastic Spray | ||
| Seal Strip | Material | EPDM | |
| Glass Cover | Material | Low iron matted tempered glass | |
| Transmissivity | ≥92% | ||
| Thickness | 3.2mm | ||
| Insulation Material | Back Side | Material | Glass Fiber + Polyurethane |
| Thickness | 20+25mm | ||
| Round Sides | Material | polyurethane | |
| Thickness | 15mm | ||
| Material of Plate Core | Aluminum plate(0.4mm) | ||
| Welding Technology of Plate Core | Laser Welding | ||
| Material and Specification of Back Plate and Sides | Aluminum Alloy δ≥0.3mm | ||
| Solar Thermal Characteristic | Film | Black Ti Film | |
| Film Technology | Strong Magnetic Voltex High Voltage adsorption | ||
| Absorptance | α=0.95±0.02 | ||
| Emittance | ε=0.05±0.02 | ||
| Physical Characteristic | Dimension(mm) | 2000×1000×130mm | |
| Net weight(kg) | 38 | ||
| Gross weight(kg) | 41 | ||
| Test Pressure | 1.2MPa,10 minutes | ||
| Working Pressure | 0.6MPa | ||
| Inner Plate | Copper Pipe | TP2 Φ22 Copper Pipe | |
| Copper Pipe Specification(mm) | Φ22×0.5 | ||
| Reed Pipes | PERM | ||
| Reed Pipe Specification(mm) | Φ10×0.5 | ||
| Plate Core Dimmension(mm) | 1950×950×0.4mm | ||
| Number of Copper Pipe | 7/8/9 | ||
