China Made Hand Sanitizer Antibacterial Gel Vacuum Mixer High Shear Homogenizer

US$5,000.00-10,000.00 1 Set (MOQ)

Basic Info.

Model NO.
TKH-500
Application
Liquid
Certification
CE, ISO
Condition
New
Stirring Type
Forced
Type
High Shear Homogenizer
Warranty
1 year
Working
Shear Mixer
Mixer Type
Homogenizer
Layout Type
Horizontal
Operating type
Cycle Operating
Transport Package
Plywood Case/Film Wrapping
Specification
4000*2900*3200
Trademark
Taikang
Origin
Wenzhou City
HS Code
8474390000
Production Capacity
500sets/Month

Product Description


High Shear Emulsifying Homogenizer is suitable for manufacturing liquid products such as pharmaceuticals, chemical, cosmetic, daily care and food industry, etc. It combines the functions of mixing, dispersing, heating and cooling, etc. We can customize according to clients' real demand.Product Features
1. The mixing tank is made of stainless steel materials.
2. The machine has a compact structure and it is easy to operate.
3. Two choices of heating: electric or steam
4. Varies types of agitator for different types of chemical
5. The motor speed is adjustable.
6. You can choose to configure a AES dissolver to accelerate material dissolution and emulsification. It can save time and labor for you.
7. HCI for showing data and monitoring.
Parameter Model TKE-20 TKE-50 TKE-100 TKE-200 TKE-500 TKE-1000 TKE-2000
Capacity(L) 20L 50L 100L 200L 500L 1000L 2000L
Agitator(kw)/Speed(rpm) 0.37/40 0.55/40 1.5/40 1.5/40 2.2/40 4/40 7.5/40
Emulsifier(kw)/Speed(rpm) 0.75/3000 1.5/3000 2.2/3000 4/3000 7.5/3000 11/3000 15/3000
Steam Heat(kw) 3 5 9 12 16 30 30
Electric Heat(kw) 9 25 27 40 50 100 120
Length(mm) 1800 2700 2950 3200 4000 3900 4900
Width(mm) 1600 2000 2100 2200 2900 3400 4300
Height(mm) 1850 2000 2200 2600 3200 3200 3600
