CE Certification Automatic Glass Grinding Polishing Machine CNC Glass Machining Center

Product Description

Product Description
Main Application
Drilling, Milling, Internal and External grinding and polishing, Writing, Shaped Notching, Engraving on glass, stone, quartz and so on
Mechanic Structure
1.The machine tool and beam adopt welded steel structure. With special heat treatment, the structure is firm and can work for a long time.
2.The machine uses automobile paint which is more rust-resistant.
3.Total weight: about 5 tons (including peripheral accessories and electric cabinet).
Mechanic Transmission
The machine is transmitted through AC servo motor by synchronic belt and synchronic belt wheel driven spindle. There is automatic lubricating system for the screw nut and guide-rail slider of the transmitting parts.
Worktable
1.There is a multi-location worktable of large size in front of the machine. With function of automatic rubdown of high precision, users can adjust the flatness of the worktable when needed. This is to keep a flat worktable.
2.There are positioning blocks for the work piece and vacuum system.
Electric Cabinet
The distributing of electric cabinet can be designed according to customer's requirements. Each terminal is clearly marked. This is convenient for the maintenance in the future.
Drawing Software
With Auto CAD software, user can design any geometrical pattern on PC with mouse and keyboard.
Safety and Reliability of Operation
1.The moving parts are lubricated by automatic lubricating system.
2. Electric cabinet adopts IP54 industrial standard and equips air-conditioner.
3.The electric parts inside electric cabinet are common products in the market which is easily changed.
4.The main fault will be automatically reminded.

Power	17KW
Model number	WD1530
Voltage	380V 50Hz
Working table area	3000MM*1500MM
Max Loading	300KG
Milling work table	3000MM*1500MM
stainless steel sheet	1.5MM
Wheel Diameter	22MM
Feature	Ease to use

---
