| Model | Drive | Blades Diameter | Blades Rotational Speed | Motor Rotational Speed | Air Flow (m³/h) | Noise Decibels (db) | Input Power (W) | Voltage (V) | Frequency (HZ) | Outline Size (H*W*T) (mm) |
| DJF-750 (24in) | Direct | 960 | 960rpm | 960rpm | 10600 | ≤70 | 370 | 220 / 380/ Customized | 50 / 60 | 750*750*510 |
| DJF-1000 (36in) | Belt | 500 | 500rpm | 1400rpm | 21000 | ≤64 | 550 | 1000*1000*450 | ||
| DJF-1100 (40in) | Belt | 470 | 470rpm | 1400rpm | 31600 | ≤64 | 750 | 1100*1100*450 | ||
| DJF-1380 (50in) | Belt | 458 | 458rpm | 1400rpm | 44000 | ≤64 | 1100 | 1380*1380*450 |
| Frame with Plastic Handle 1. Frame: Hot Galvanized sheet with zinc thickness of 275g/sqm, high anti-corrosion performance 2. Plastic Handle, easy to carry , Convenient to load Advantage: YUYUN SANHE has the advanced Complete CNC machine and Laser Cutting machine. Auto punching and bending, the accuracy of the hole is 100%, easy to assemble. | |
| Belt Pulley 1. Material: High strength aluminum-magnesium alloy by die-casting. 2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability Advantage: Light weight, Low vibration ,attractive appearance. | |
| Bearing Imported double-row bearing with special waterproof design. Advantage: High strength, low noise, free maintenance and long service life. | |
| Centrifugal System 1.Material: High quality Nylon PA66 2.Guide Rod: 304 stainless steel with special material outside, high strength, no rust, reduce friction. 3.Rivet: 304 stainless steel , wear-resisting, no rust. Advantage: It can keep the shutters open at complete 90 degree to ensure the lowest air resistantce and biggest air volume. | |
| Fan Blades 1. Material : 430 stainless steel, thickness 1.2mm 2. Diameter: 1270mm Advantage: Large air flow, no deformation, no fracture, no dust, attractive and durable. Note: Blade material also have galvanized sheet, aluminum alloy for option | |
| Belt Brand: Mitsuboshi belt (Japanese) Type: B type, B88 Advantage: B type belt is 3 times longer service life than A type belt, maintenance free. | |
| Shutters 1. Material: Hot Galvanized sheet with zinc thickness of 275g/sqm 2. Shutter Fixed Parts: High quality nylon. Advantage: High anti-corrosion performance, open flexibly, long service life, no deformation ,no rust, running stable. | |
| Motor Fixed Nuts and Washer 1. Hexagon Nuts 2. Stainless Steel Washer Advantage: More firmly, never loosen. Not rust, Easy to change Motor.. |
