| RG59 Coaxial Cable |
| | Options: | Standard Specification |
| Inner conductor | Material | CCS/COPPER/CCA | 0.81mmBare Copper+3.7mmFoam PE+AL Foil+60% Braid+6.1mm PVC |
| Diameter | 0.6mm/0.7mm/0.8mm |
| Dielectric | Material | Foam PE/Solid PE |
| Diameter | 3.6mm-3.8mm |
| Shield | 1st shield | Al foil/copper foil |
| 2nd shield | Al-Mg /CCAM/Copper/TC |
| Tri- shield | Al foil/copper foil |
| Qual-shield | Al-Mg /CCAM/Copper/TC |
| Jacket | Material | PVC or PE /PVC Degree: 65,68,70,75 /white or black |
| Diameter | 6.0mm-6.1mm |
| Packing | 15m,20m etc short meter with F , DC+BNC connectors . |
| 100m coil, 6 rolls per carton . |
| 305m with wooden drum/plastic spool, or inner color box, pulling box, outer cartons etc. |
