Corsair Rmx Series RM850X 850 W ATX12V / EPS12V 80 Plus Gold Certified Full Modular Power Supply

US$89.00-119.00 10 Pieces (MOQ)

Basic Info.

Model NO.
CP-9020235-NA
Power
>800W
ATX Standard
ATX 12V 2.3
Fan Type
13.5cm
Fan Size
≤8"
Feature
Module
Hard Disk Interface
≥8
80PLUS Certification
80 PLUS Gold
Modular
Modular
Mtbf
100,000 Hours
Main Connector
24 Pin
PCI-Express Connector
6 X 6+2-Pin
SATA Power Connector
14
Input Voltage
100 - 240 V
Input Current
10- 5 a
Weight
3.75 Lbs
Warranty
5 Year
Transport Package
Original Boxed
Specification
3.39 x 5.91 x 6.30 inch
Trademark
CORSAIR
Origin
China
HS Code
8504409950
Production Capacity
1000 Pieces/Per Month

Product Description

Product Description General Brand Series Model
CORSAIR
RMx Series (2021) RM850x
CP-9020200-NA
Details Type Maximum Power Fans Main Connector +12V Rails PCI-Express Connector SATA Power Connector Modular Energy-Efficient Over Voltage Protection Input Voltage Input Frequency Range Input Current Output MTBF Approvals Max PSU Length Connectors Cable Spec
ATX12V / EPS12V
850 W
1 x 135mm Magnetic Levitation Fan
24Pin
Single
4 x 6+2-Pin
14
Full Modular
80 PLUS GOLD Certified
Yes
100 - 240 V
47 - 63 Hz
10A - 5A
+3.3V@20A, +5V@20A, +12V@70.8A, -12V@0.3A, +5VSB@3A
100,000 hours
FCC, ICES, CE, UL / CUL, CSA, C-Tick/RCM, TUV, CB, CU, KC Mark, RoHS, WEEE, RoHS (China), REACH
160 mm
1 x 24 pin ATX
3 x 8 pin (4+4) EPS (CPU)
4 x 8 pin (6+2) PCIe
14 x SATA
4 x 4 pin Peripheral
24Pin MB: One cable (610mm)
4+4Pin CPU: Three cables (650mm)
2 x PCI 6+2Pin: Two cables (600+150mm)
4 x SATA: Two cables (505+115+115+115mm)
3 x SATA: Two cables (520+115+115mm)
4 x 4pin PERIPHERAL: One cable (450+100+100+100mm)
Features Features
Fully Modular: Only connect the cables your system needs, making clean and tidy builds easier.
135mm Magnetic Levitation Fan: Utilizes a magnetic levitation bearing and custom engineered rotors for high performance, low noise, and superior reliability.
EPS12V Connector: For wide compatibility with modern graphics cards and motherboards.
100% All Japanese 105°C Capacitors: Premium internal components ensure unwavering power delivery and long-term reliability.
Modern Standby Compatible: Extremely fast wake-from-sleep times and better low-load efficiency.
80 PLUS Gold Certified: High efficiency operation for lower power consumption, less noise, and cooler temperatures.
Zero RPM Fan Mode: At low and medium loads the cooling fan switches off entirely for near-silent operation.
Resonant LLC Topology with DC-to-DC Conversion: Provides clean, consistent power, reduces coil whine for quieter operation, and enables use of more energy efficient sleep states.
Dimension & Weight Dimensions Weight
3.39" x 5.91" x 6.30"
3.75 lbs.
Package Package Content
RM850X
Safety leaflet
AC cable
DC cable set
Mounting screws
Cable ties
