Product Description
Product Description
Company InformationShenzhen Xiongyihua Plastic Insulation Limited was established in 2006 in Shenzhen, after more than decades of continuous efforts , has developed into a professional integrated manufacturer of specializes in production and development Engineering Plastic and Insulation Plastic ,is the most complete varieties. We have automatic dipping production lines, CNC carving machine and laser engraving machine, along with several saws, milling, planing,grinding, drilling, tapping, punching, cutting and other machining large production equipment. Our main products :1.Insulation Plastic Series : 3240/FR-4/G10 Epoxy Fiberglass ,Bakelite,3025 Phenolic Cotton Cloth Laminated,3021 Phenolic Paper Laminated,High Voltage Insulation Plastic.2.Engineering Plastic Series: PA6/MC Nylon ,POM, PTFE,PVC,PE,PU,Acrylic,ABS and so on.3. Insulation Machining Parts Series : Customized according to the customers’ drawings and designs,welcome to contact us for more details. Our well-equipment facilites and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. As a result of our products and outstanding customer service, we have gained a global sales network reaching India, Vietnam, Thailand, Indonesia, Philippines, Malaysia, Turkey, Pakistan, Dubai, and some other countries from European, like Brirain, France and German. And America, Australia, etc,enjoying great reputation in plastic industry. If you are interested in doing business with us, freely send your inquiry and warmly welcome to visit our website to check more information and products details. Our experienced and knowledgeable staff will meet your needs and exceed your expectations. insulation plastic fr4 epoxy glass laminate sheet Detailed Product DescriptionFR4 fiber glass sheet size:1020*1220mm thickness:0.2-50mmHigh mechanical property Stable dielectric property good resistance to Waterlogging.Widely used in electrical appliances,as insulating parts in Generator and Motor. 3240 Epoxy phenolic glass cloth laminted Sheet1.Define and purposeThis product is a kind of laminated board formed through heat pressing after the electric industry fiolax cloth dips into epoxy resin. It is suitable as the mechanical, electric and electronic insulation structural components which are used under room and middle temperatures with a certain mechanical performance and electric performance requirement. 2.Technical requirement.2.1 Outside appearance.The board material should be flat and smooth, no bubble, no wrinkle, no crackle, free from other defect, such as scrape, compress, dirt spot and uneven of color, allow a few of color spots. Sr.PerformanceUnitTest methodIndex value1Vertical layer direction bending strengthMPaGB/T5130 section 5.1≥ 1522Parallel layer direction compact strength(Simple strut-beam)KJ/m2GB/T5130 section 5.5≥ 253Parallel layer direction compact strength(Suspended arm beam method)KJ/m2GB/T5130 section 5.5≥ 264Relative dielectric factor (1 MHZ below) GB/T5130 section 6.2≤5.55Mediate loss factor(1 MHZ below) GB/T5130 section 6.2≤ 0.046Vertical layer direction electric strength at (90±2)°c oil.MV/mGB/T5130 section 6.1Refer to table 27Parallel layer direction breakdown voltage at (90±2)°c oil.kVGB/T5130 section 6.1≥ 158Insulation resistance after water dippingΩGB/T5130 section 6.3≥ 3.0 × 1089Densityg/cm3GB/T5130 section 8.11.7-2.010Water absorptionmgGB/T5130 section 8.2Refer to table 3 Table 2: Vertical layer direction electric strength Average thickness mmElectric strength MV/mmAverage thickness mmElectric strength MV/mmAverage thickness mmElectric strength MV/mm0.4≥ 16.91.0≥ 14.22.2≥ 11.40.5≥ 16.11.2≥ 13.72.4≥ 11.10.6≥ 15.61.4≥ 13.22.5≥ 10.90.7≥ 15.21.6≥ 12.72.6≥ 10.80.8≥ 14.81.8≥ 12.22.8≥ 10.50.9≥ 14.52.0≥ 11.83.0≥ 10.2 Note: .1. For the vertical layer direction electric strength at 90°c ±2°c oil, you can select either in 20s pressure rising-up gradually test requirement or in 1mm withstand pressure test requirement. For the material meeting with requirement of either one, its vertical layer direction electric strength at 90°c ±2°c oil is deemed to meet with this standard requirement..2. If the arithmetical mean of measured thickness of specimen is between two thickness values in table, its indicated value should be calculated out by interpolation. If arithmetical mean of measured thickness is less than 0.4mm, its electric strength index value≥ 16.9MV/m is taken out. If its nominal thickness is 3mm and the arithmetical mean of measured thickness is more than 3mm, its electric strength Index value≥ 10.2MV/m is taken out. Table 3: Water absorption Sample thickness mean value(d) mmWater absorptionmgSample thickness mean value(d) mmWater absorption mg0.4 <= d ≤ 1.0≤ 186.0 < d ≤ 10≤ 301.0 < d <= 2.0≤ 2010.0 < d≤ 20≤342.0 < d <= 3.0≤ 252.0 < d ≤ 25≤ 523.0 < d <= 6.0 Factory Information:Shenzhen Xiongyihua Plastic Insulation Limited was established in 2006 in Shenzhen, is a manufacturer and trader, specialized in the research , development and production of Engineering Plastic and Insulation Plastic , such as phenolic laminated , epoxy fiberglass, nylon PA6 , POM,PE,PVC,PU,PTFE , ABS ,PETG,PEEK ,PMMA,HDPE and other related plastic products .We have a great team with experienced technical and management personnel .Besides fabrication facilities to manufacture plastic products , we also have processing equipment ,like CNC carving machine and laser and engraving machine to engraving , cutting ,bending and drilling .We have gained a global sales network reaching Vietnam , Thailand ,Indonesia , Philippines , Malaysia, Pakistan ,Dubai, and some other countries form European , like Britain,France and German , and America ,Australia etc.
>>
