Stainless Steel Coil Decoilers Machine for Stamping Sheet Metal and Feeder Flattening Machines

Product Description

Our Advantages
About this product
Unique Advantages of Our Standard Decoiler Machines:
1. Superior Construction: Our decoiler machines are built on a solid foundation using national standard H-shaped steel for the base. This provides superior load-bearing capacity and enhanced stability compared to the I-shaped steel used by most manufacturers in their decoiler machines.
2. Enhanced Strength: The main body of our decoiler machines undergoes a bending treatment rather than traditional welding. We further reinforce our machines with supporting tiles and back wheels made from thickened cold-drawn flat steel. This significantly bolsters the overall strength of the machine body.
3. Reinforced Design: Our design includes a back arc that is bent to reinforce the strength of the fuselage, a feature you won't find in most decoilers that use thin sealing plates.
4. Long-Term Durability: We've addressed the common issue of main shafts falling off after prolonged use. Our main shaft inside the body is securely fastened with square nuts, offering a more durable solution than the gasket screws used by many other manufacturers.
Product Description
Heavy-duty material rack, high-quality decoiler machine

Durable support tiles
The tiles are made of A3 material, after cutting, flash processing.remiling tile bevel, bending, drilling and milling groove procedures.

Electric control box
Clear and simple equipment buttons make operation more convenient and are a good helper for production
A-type iron
It ensures that the material coil remains level with the production line during unwinding and prevents the material strip from deflecting
Hand Crank Link Type Expansion
It allows for easy adjustment of coil size, ensuring a perfect fit every time.
Product Parameters

Model	LJA SD-200	LJA SD-300	LJA-400	LJA-500	LJA-600	LJA-800	LJA-1000	LJA-1500
Material width	200mm	300mm	400mm	500mm	600mm	800mm	1000mm	1500mm
Material thickness	0-1.6mm	0-3mm	0-3mm	0-3mm	0-3mm	0-3mm	0-3mm	0-3mm
Material inner diameter	300-460	450-530	450-530	450-530	450-530	450-530	450-530	450-530
Material outer diameter	800mm	1200mm	1200mm	1200mm	1200mm	1200mm	1200mm	1200mm
Material maximum weight	800kg	1000kg	2000kg	3000kg	>3000kg	>3000kg	>3000kg	>3000kg

Note: We can Customize inner diameter, outer diameter and max load weight Hot Products
Company Profile
* About Anhui LJA Metal Tech Co., Ltd
We are a leading manufacturer specializing in metal processing machinery, committed to providing high-quality and innovative solutions for industries worldwide. With decades of experience in the industry, we have grown from a small workshop to an internationally recognized manufacturer with a global customer base. Over the years, we have built a reputation for excellence in designing and producing a wide range of advanced machines, including decoiler machines, pipe punching machines, plasma cutting machines, pipe forming machines, metal polishing machines, and pipe bending machines. These products are engineered with precision, offering superior performance and durability to meet the ever-evolving demands of diverse industries.
>>> After-sale Service
1. Global Installation & Commissioning
• On-site service by certified engineers within 5 working days (remote areas negotiable).
• Pre-installation video guidance & post-installation inspection report.
2. Multilingual Training
• Basic: 2-hour live demo (on-site/online) + multilingual operation videos/manuals.
• Advanced: Customized sessions for technical teams (PLC programming/data analysis).
3. 24/7 Support
• 3-tier response:
Critical failure: 15-min remote diagnosis + spare parts priority shipping
General issues: 30-min video call troubleshooting
Inquiries: 1-hour email reply
4. Global Spare Parts
• 2 years for main motor.
• Except for consumables and consumables, other parts are for 1 year. Extended service is always available. Free repair and replacement of parts within warranty. Only replacement of parts, shipping costs are borne by the customer..
Value-Added Options
▸ Annual Maintenance Contract (AMC): 20% discount on parts + bi-annual preventive checks
▸ Extended Warranty: Up to 5 years coverage

Certifications
FAQ
Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service. At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.

Q: If we are interested in your machine, how do we choose?
1. What main job you do with the machine?
2. What is your request? diameter__mm, thickness__mm, length__mm?
3. What material you want to process, stainless steel, carbon steel?

Q: How about warranty?
A: 2 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world, We need your machines running in order to keep your business running.
Q: Can you customize?
A: Yes, non-standard machines can be customized according to your products

---
